Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 180mm -
Travel Rear 180mm -
Fork Fox Float 36
-
Groupset X0, SLX -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
M5 manipulated alloy, ORE TT/DT, tapered and forged HT, ISCG mount, 142mm dropouts, full cartridge bearing pivots and shock yoke, replaceable derailleur hanger, derailleur guard, 180mm travel
Suspension Fork
Fox 36 Van R, coil spring, tapered alloy steerer, preload and reb adj. 20mm thru-axle, 180mm
Rear Shock
Custom Fox Van RC, coil over w/piggy back, compression and rebound adj. 8.5x2.5"", S: 450, M: 500, L: 550,
Drivetrain
Rear Derailleur
SRAM X0, 10-speed, mid carbon cage
Front Derailleur
Shimano FD-M660 SLX, E-type for DMD, top swing, bottom pull
Shift Levers
SRAM X7, 10-speed, aluminum trigger, w/MatchMaker clamp
Cassette
SRAM PG-1030, 10-speed, 11-36t
Crank
Truvativ Descendant, 7050 alloy arms, double ring, with Gamut shiftguide
Bottom Bracket
SRAM GXP outboard bearing
Chain
KMC X-10, 10-speed, w/ reusable Missing Link, nickel plates
Pedals
Specialized Benies low profile with removable pins
Wheels
Front Hub
Specialized Hi Lo disc, laser-etched logo, sealed cartridge bearing, 20mm thru-axle, 32h
Rear Hub
Specialized Hi Lo 142 disc, laser-etched logo, double-sealed cartridge bearing, 12mm thru-axle, 32h
Rims
Roval DH
Spokes
DT Swiss Industry stainless 2.0, (14g)
Tires
Specialized Butcher SX, 60 TPI, aramid bead, soft dual-compound, 26x2.3""
Brakes
Brakes
Custom Avid Elixir 7, hydraulic disc, metallic pad, HS-1 rotor, 200mm rotor
Brake Levers
Avid Elixir 7 hydraulic, w/MatchMaker clamp
Cockpit
Stem
Specialized DH, forged, 35mm length, 4-bolt, 31.8mm
Handlebar
Specialized Demo low-rise bar, 7050 alloy, 750mm wide, 8º backsweep, 6º upsweep, 31.8mm
Grips
Specialized lock-on, S/M: Grappler, Others: Grappler XL
Headset
1-1/8"" cartridge alloy upper and 1-1/2"" lower, cartridge bearings
Seat
Saddle
Specialized DH, 8mm hollow Cr-Mo rails
Seatpost
2014 butted alloy, single bolt setback, 30.9mm, S/M: 350mm, others: 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.39 mm | 1.32 mm |
| Bottom Bracket Height | 356 mm | 356 mm | 356 mm |
| Stack | 588 mm | 588 mm | 588 mm |
| Reach | 406 mm | 423 mm | 447 mm |
| Top Tube Length | 570 mm | 588 mm | 611 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 394 mm | 419 mm | 458 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 112 mm | 112 mm | 112 mm |
| Chainstay Length | 413 mm | 413 mm | 413 mm |
| Wheelbase | 1153 mm | 1171 mm | 1194 mm |
| Bottom Bracket Drop | -13 mm | -13 mm | -13 mm |
| Standover Height | 725 mm | 728 mm | 734 mm |
| Wheels | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
SX Trail completes the Specialized Sx model. Specialized released 15 bikes variations of this model so far. You can get a glimpse at all models from 2012, by clicking on this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Downhill bikes
Our math shows that the average cost of a dependable Downhill bike is 3391$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Downhill bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork
This bike has the Fox Float 36 fork installed. The fork’s travel is 180mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Fork material
When it comes to the fork, this bike has an aluminum one, which is a lighter material. However, it is not as tough, nor durable as steel is.
Rear Shock
The shock that’s installed on this bike is Custom Fox Van RC, with a travel distance of 180mm. Rear shocks improve riding comfort and give you greater control over all terrains. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
The SX Trail 2012 bike is equipped with 26″ carbon wheels when leaving the factory. These wheels give you great handling over your bike. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Specialized SX Trail has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
SX Trail comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, you won’t have a problem finding one that suits you.
