Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 160mm -
Travel Rear 170mm -
Fork Fox Float 36
-
Groupset X0, SLX -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SX Trail M5 Manipulated Alloy frame, ORE TT/DT, forged HT, low center of gravity design, full cartridge bearing pivots, ISCG mount, replaceable derailleur hanger, derailleur guard, 170mm travel
Suspension Fork
Fox 36 Van RC2, 160mm travel, low/high speed compression and rebound adj. 20mm thru-axle, alloy steerer
Rear Shock
Fox DHX 5.0 coil 7.875x2.25"", rebound adj. ProPedal, and bottom out control, S, 500, M: 550, L: 600 springs
Drivetrain
Rear Derailleur
SRAM X-0, 9-speed, mid cage
Front Derailleur
Shimano M660 SLX, DMD, top swing, dual pull
Shift Levers
SRAM X-9, trigger
Cassette
Shimano HG61, 9-speed, 11-34t
Crank
Truvativ Stylo, 170mm, w/ Gamut Shift chain guide
Bottom Bracket
Truvativ Stylo, outboard bearing
Chain
SRAM PC-971, 9-speed w/Power Link
Pedals
Specialized Lo-Pro Mag, magnesium platform, 9/16"" oversized heat treated Cr-Mo axle, sealed cartridge bearing, removable allen bolt pins
Wheels
Front Hub
Specialized Hi-Lo disc, 20mm thru axle, 32h
Rear Hub
Specialized bolt on, 135mm, hollow 10mm Cr-Mo axle w/ RD guard
Rims
Custom DT Swiss F550, 30mm, 32h
Spokes
DT Swiss Competition 2.0/1.8/2.0mm stainless, black, alloy nipples
Tires
Specialized Clutch SX 26x2.3"", 60 TPI, aramid bead, cap ply, soft dual compound
Brakes
Brakes
Custom Avid Elixir R Carbon, hydraulic disc, carbon lever blade, reach adjust, metallic pads, ss hardware 203mm rotor
Brake Levers
Custom Avid Elixir R Carbon Hydraulic, tool-less adj. reach
Cockpit
Stem
Specialized Aggro stem, 35mm extension, OS 31.8, 4-bolt, forged
Handlebar
Specialized Enduro mid rise bar, 2014 alloy, 31.8mm, 6 degree up, 9 degree backsweep, 660mm wide
Grips
Specialized thin lock on grip, alloy bar ends
Headset
1-1/8"" to 1.5"" Threadless, alloy, cartridge bearing
Seat
Saddle
Specialized Enduro, 8mm Cr-Mo rails, SL foam
Seatpost
Thomson Elite Straight w/ 12 degree clamp, 367mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Bottom Bracket Height | 356 mm | 356 mm | 356 mm |
| Top Tube Length | 568 mm | 586 mm | 609 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 394 mm | 419 mm | 470 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 120 mm | 120 mm | 120 mm |
| Chainstay Length | 413 mm | 413 mm | 413 mm |
| Wheelbase | 1143 mm | 1161 mm | 1184 mm |
| Bottom Bracket Drop | -13 mm | -13 mm | -13 mm |
| Standover Height | 694 mm | 693 mm | 729 mm |
| Wheels | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
SX Trail II belongs to the Specialized Sx model. Specialized launched 15 bikes of this model so far. Check out the entire range from 2009 of this model, by clicking this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Downhill bikes average price
According to our calculations, the average cost of a Downhill bike that is reliable is 3391$. However, this doesn’t mean that if you spend less money on a Downhill bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Overview of components
Fork
The fork installed on this bike is the Fox Float 36 model. The travel on this model is 160mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Fork material
SX Trail II has an aluminum fork, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Rear Shock
Specialized SX Trail II bike has the Fox DHX 5.0 coil 7.875×2.25″” model installed, and has a travel of 170mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
As for the wheels, Specialized SX Trail II 2009, has a 26″ aluminum model. Being a little smaller, these wheels will fit both small and tall riders. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The SX Trail II comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
Specialized SX Trail II bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, it won’t take much to find one that’s right for you.
