Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 26" -
Travel Front 180mm -
Travel Rear 180mm -
Fork Fox Float 36
-
Groupset X0, SLX -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
M5 manipulated ally, ORE TT/DT, tapered and forged HT, ISCG mount, 142mm dropouts, full cartridge bearing pivots and shock yoke, replaceable derailleur hanger, derailleur guard, 180mm travel
Suspension Fork
Fox 36 Van RC2, tapered alloy steerer, low/high speed compression and rebound adj. 20mm thru-axle, 180mm travel
Rear Shock
Fox DHX RC4, coil over w/piggy back, rebound and High/Low speed compression and bottom-out control adj. 8.5x2.5"", S:450, M:500, L:550
Drivetrain
Rear Derailleur
SRAM X.0, 9-speed, mid cage
Front Derailleur
Shimano FD-M660 SLX, E-type for DMD, top swing, bottom pull
Shift Levers
SRAM X.9, 9-speed, aluminum trigger
Cassette
Shimano HG61, 9-speed, 11-34t
Crank
BlackBox SRAM Descendant, 7050 alloy arms, 9-speed double, with Gamut Shift Guide
Bottom Bracket
SRAM GXP, outboard bearing
Chain
SRAM PC-971, 9-speed w/Power Link
Pedals
Specialized Lo-Pro Mag, removeable pins, 9/16""
Wheels
Front Hub
Specialized Hi Lo disc, laser-etched logo, sealed cartridge bearing, 20mm thru-axle, 32h
Rear Hub
Specialized Hi Lo 142 disc, laser-etched logo, double sealed cartridge bearing, 32h
Rims
Custom DT Swiss F550, 30mm wide, 32h
Spokes
DT Swiss Competition 2.0/1.8/2.0mm stainless
Tires
Specialized Butcher SX, 60 TPI, aramid bead, soft dual compound, 26x2.3""
Brakes
Brakes
Custom Avid Code X.0, hydraulic disc, tool-less reach and pad contact adj. Code caliper, metallic pads, stainless hardware, 203mm rotor
Brake Levers
Custom Avid Code X.0 hydraulic, tool-less reach and pad contact adj. X.0 carbon lever blade
Cockpit
Stem
Specialized DH, forged, 35mm length, 4-bolt, 31.8mm
Handlebar
Specialized Demo low-rise bar, 7050 alloy, 750mm wide, 8 degree backsweep, 6 degree up, 31.8mm
Grips
Specialized lock-on, S/M: Grappler, Other: Rocca
Headset
1-1/8"" cartridge alloy upper and 1.5"" lower, cartridge bearings
Seat
Saddle
Specialized Demo, 7mm hollow Cr-Mo rails
Seatpost
Thomson straight w/ 12 degree clamp, 367mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.39 mm | 1.32 mm |
| Bottom Bracket Height | 356 mm | 356 mm | 356 mm |
| Stack | 588 mm | 588 mm | 588 mm |
| Reach | 406 mm | 423 mm | 447 mm |
| Top Tube Length | 570 mm | 588 mm | 611 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 394 mm | 419 mm | 458 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 112 mm | 112 mm | 112 mm |
| Chainstay Length | 413 mm | 413 mm | 413 mm |
| Wheelbase | 1153 mm | 1171 mm | 1194 mm |
| Bottom Bracket Drop | -13 mm | -13 mm | -13 mm |
| Standover Height | 725 mm | 728 mm | 734 mm |
| Wheels | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
SX Trail II belongs to the Specialized Sx model. 15 bikes variations carry this model name so far. You can get a glimpse at all models from 2011, by clicking on this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Downhill bikes average price
If you want an acceptable Downhill bike you should know that the average price is 3391$. However, even though the average price of a Downhill bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
SX Trail II components
Fork
Specialized SX Trail II 2011 bike is equipped with the Fox Float 36 fork, and has 180mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Fork material
The fork on this bike is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Rear Shock
From the factory, it comes with the Fox DHX RC4 rear shock model, which has a travel of 180mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
As for the wheels, Specialized SX Trail II 2011, has a 26″ aluminum model. Being a little smaller, these wheels will fit both small and tall riders. However, they provide less traction than 29″ wheels do.
Brakes
When you want to stop the bike in time, the brakes are vital. The SX Trail II has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
SX Trail II comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, finding one for you shouldn’t be a problem.
