Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra Di2 -
Suspension Rigid -
Drivetrain 2 × 11 Electronic -
Brakes Rim
Sizing
Recommended size guide.
49cm
155cm - 163cm
52cm
161cm - 169cm
54cm
166cm - 175cm
56cm
172cm - 181cm
58cm
178cm - 186cm
61cm
183cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
FACT 10r carbon, OSBB, full internal cable routing, internally integrated seat clamp, 130mm rear spacing
Suspension Fork
S-Works FACT carbon, full monocoque, size-specific taper
Drivetrain
Rear Derailleur
Shimano Ultegra Di2, 6870, 11-speed
Front Derailleur
Shimano Ultegra Di2 6870, 11-speed, braze-on
Shift Levers
Shimano Ultegra Di2, 6870, 11-speed
Cassette
Shimano Ultegra, 11-speed, 11-28t
Crank
Specialized Pro Carbon 52/36T
Bottom Bracket
Enduro BB30
Chain
Shimano HG70, 11-speed
Wheels
Rims
Roval CL 40, carbon 40mm rim depth, DT Swiss 350 internals, 24h
Tires
S-Works Turbo, 700x24mm, 220TPI, folding bead, BlackBelt protection
Brakes
Brakes
Shimano Ultegra
Cockpit
Stem
Specialized Pro SL, alloy, 4-bolt
Handlebar
Specialized Expert Shallow Drop, alloy, 123mm drop, 75mm reach
Seat
Saddle
Toupé Pro, Adaptive Edge design, carbon rails, 143mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.31 mm | 1.37 mm | 1.41 mm | 1.43 mm | 1.47 mm | 1.5 mm |
| Bottom Bracket Height | 270 mm | 270 mm | 272.5 mm | 272.5 mm | 274 mm | 274 mm |
| Front Center | 576 mm | 576 mm | 583 mm | 591 mm | 605 mm | 612 mm |
| Rake | 45 mm | 45 mm | 45 mm | 43 mm | 43 mm | 43 mm |
| Trail | 62 mm | 57 mm | 57 mm | 56 mm | 56 mm | 53 mm |
| Stack | 501 mm | 523 mm | 540 mm | 561 mm | 588 mm | 609 mm |
| Reach | 383 mm | 383 mm | 384 mm | 392 mm | 399 mm | 405 mm |
| Top Tube Length | 515 mm | 534 mm | 545 mm | 562 mm | 579 mm | 597 mm |
| Seat Tube Angle | 75.5 ° | 74 ° | 73.5 ° | 73.25 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 431 mm | 462 mm | 481 mm | 501 mm | 522 mm | 553 mm |
| Head Tube Angle | 72.25 ° | 73 ° | 73 ° | 73.5 ° | 73.5 ° | 74 ° |
| Head Tube Length | 100 mm | 120 mm | 140 mm | 160 mm | 190 mm | 210 mm |
| Chainstay Length | 402 mm | 402 mm | 402 mm | 402 mm | 404 mm | 407 mm |
| Wheelbase | 967 mm | 967 mm | 975 mm | 983 mm | 1000 mm | 1010 mm |
| Bottom Bracket Drop | 71 mm | 71 mm | 69 mm | 69 mm | 67 mm | 67 mm |
| Standover Height | 727 mm | 752 mm | 772 mm | 792 mm | 823 mm | 847 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 161 cm | 166 cm | 172 cm | 178 cm | 183 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm | 181 cm | 186 cm | 191 cm |
About this model
Tarmac Pro Ultegra Di2 belongs to the Specialized Tarmac model. Specialized released 279 bikes variations of this model so far. Check out the entire range from 2017 of this model, by clicking this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Race bikes average price
According to our calculations, the average cost of a Race bike that is reliable is 3350$. However, this doesn’t mean that if you spend less money on a Race bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Tarmac Pro Ultegra Di2 components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
When leaving the production line, the Tarmac Pro Ultegra Di2 model has 700c carbon wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes deliver an average performance overall. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
There are 6 sizes available for this model. Rider height can be anywhere between 155 cm – 191 cm (5.09 ft – 6.27 ft). In conclusion, finding one for you shouldn’t be a problem.
