Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Claris -
Suspension Rigid -
Drivetrain 3 × 8 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Specialized A1 Premium Aluminum, smooth weld, fully manipulated tubing, semi-compact design, integrated headset, internal cable routing, rack and fender fittings
Suspension Fork
Full alloy, low-rider rack/fender fittings
Drivetrain
Rear Derailleur
Shimano 2300
Front Derailleur
Shimano 2300
Shift Levers
Shimano 2300 STI
Cassette
Shimano HG-50, 8-speed, 13-26t
Crank
Shimano 2300 triple
Bottom Bracket
Cr-Mo axle, 68mm x 113mm
Chain
KMC Z-51 nickel plate
Pedals
Nylon flat test ride, loose ball, w/ reflectors
Wheels
Front Hub
Forged aluminum, sealed bearing, QR, 32h
Rear Hub
Forged aluminum, double-sealed, cassette, QR, 32h
Rims
Alex S480, 32h
Spokes
Stainless 14g
Tires
Specialized Borough CX Sport, 60 TPI, wire bead, 700x32c
Brakes
Brakes
Tektro CR-520 wide canti
Brake Levers
New TriCross secondary brake levers
Cockpit
Stem
Specialized EliteSet, 3D forged alloy, 12-degree, 4-position adjustable, 4-bolt, 31.8mm clamp
Handlebar
Specialized H2 Ergo Comp, alloy
Headset
1-1/8"" sealed Cr-Mo cartridge bearings integrated w/ headset, 20mm alloy cone spacer, w/ 20mm of spacers
Seat
Saddle
Body Geometry Riva Plus TriCross, 155mm
Seatpost
New Specialized Sport, alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.53 mm | 1.6 mm | 1.56 mm | 1.59 mm | 1.61 mm | 1.66 mm |
| Bottom Bracket Height | 265 mm | 265 mm | 265 mm | 267 mm | 267 mm | 269 mm | 269 mm |
| Front Center | 593 mm | 597 mm | 593 mm | 601 mm | 604 mm | 607 mm | 614 mm |
| Rake | 51 mm | 49 mm | 49 mm | 49 mm | 47 mm | 47 mm | 47 mm |
| Trail | 75 mm | 74 mm | 64 mm | 64 mm | 63 mm | 60 mm | 57 mm |
| Stack | 528.5 mm | 544.7 mm | 578.5 mm | 572.7 mm | 589.5 mm | 603.7 mm | 629.6 mm |
| Reach | 352 mm | 357 mm | 362.2 mm | 366.1 mm | 371 mm | 374 mm | 379 mm |
| Top Tube Length | 497 mm | 508 mm | 529 mm | 541 mm | 552 mm | 562 mm | 579 mm |
| Seat Tube Angle | 76 ° | 75.5 ° | 74 ° | 73.5 ° | 73.25 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 460 mm | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 69.5 ° | 70 ° | 71.5 ° | 71.5 ° | 72 ° | 72.5 ° | 73 ° |
| Head Tube Length | 105 mm | 120 mm | 130 mm | 145 mm | 160 mm | 175 mm | 200 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1015 mm | 1019 mm | 1015 mm | 1024 mm | 1027 mm | 1030 mm | 1037 mm |
| Bottom Bracket Drop | 71 mm | 70 mm | 71 mm | 69 mm | 69 mm | 67 mm | 67 mm |
| Standover Height | 726 mm | 753 mm | 772 mm | 789 mm | 807 mm | 825 mm | 851 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Tricross is part of the Specialized Tricross model. 27 bikes variations carry this model name so far. You can easily view all of the Specialized Tricross bikes models from 2012, here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Touring bikes average price
According to our math, the average price for a trustworthy Touring bike is 1007$. However, you could also get a good Touring bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork material
The fork on this bike is made out of aluminum, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels size
The Tricross 2012 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Specialized Tricross has Rim brakes installed. Rim brakes deliver an average performance overall. However, you could spend a little extra and get a bike that has hydraulic brakes.
