Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Rival, FSA -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Sizing
Recommended size guide.
49cm
155cm - 163cm
52cm
161cm - 169cm
54cm
166cm - 175cm
56cm
172cm - 181cm
58cm
178cm - 186cm
61cm
183cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Specialized E5 SLX aluminum, fully manipulated tubing, smooth weld semi-compact Freeroad design, FACT carbon seatstays w/ Zertz inserts, rack and fender fittings
Suspension Fork
S-Works FACT carbon, monocoque construction, full carbon legs, crown and steerer w/ Speed Zertz, rack and fender fittings
Drivetrain
Rear Derailleur
SRAM Rival
Front Derailleur
SRAM Rival, 31.8mm clamp, bottom pull
Shift Levers
SRAM Rival Double Tap
Cassette
Shimano 105, 10-speed 12-27t
Crank
FSA SL-K MegaExo, 2-piece carbon crankset
Bottom Bracket
FSA MegaExo, integrated exterior cartridge bearings, alloy
Chain
SRAM 1050R, 10-speed
Pedals
Silver cage, black body, w/ toe clip and strap
Wheels
Front Hub
Roval Pave SL, 20 hole, cold forged alloy five-spoke high flange, adjustable alloy axles, Roval QR
Rear Hub
Roval Pave SL, 24h, cold forged alloy five-spoke high flange, adjustable alloy axles, Roval QR
Rims
Roval Pavé SL, E5 alloy mid-profile, machined brake surface
Spokes
DT aero butted
Tires
Specialized Houffalize CX Pro, 700x32c, dual-compound tread, aramid bead, 120TPI
Brakes
Brakes
Tektro high profile linear spring cantilever, alloy, cartridge pads
Brake Levers
SRAM Rival, 10-speed Double Tap
Cockpit
Stem
Specialized Pro-Set, 3D forged alloy, 4-bolt 31.8mm bar clamp, 4-position adjustable
Handlebar
Specialized Comp, 6061 alloy, short drop, ergonomic shaping, 31.8mm
Headset
Specialized Mindset, 1-1/8"" integrated threadless, sealed cartridge bearings, 25mm alloy cone w/ one 10mm and two 5mm alloy spacers
Seat
Saddle
Body Geometry Phenom SL, super light foam, carbon reinforced base, Cr-Mo rails, microfiber cover
Seatpost
Specialized Pavé II, FACT carbon w/ Zertz insert, aluminum head, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Bottom Bracket Height | 265 mm | 265 mm | 267 mm | 267 mm | 269 mm | 269 mm |
| Front Center | 596 mm | 597 mm | 597 mm | 601 mm | 607 mm | 616 mm |
| Rake | 49 mm | 49 mm | 49 mm | 47 mm | 47 mm | 47 mm |
| Trail | 75 mm | 70 mm | 65 mm | 64 mm | 61 mm | 58 mm |
| Top Tube Length | 520 mm | 535 mm | 550 mm | 565 mm | 580 mm | 600 mm |
| Seat Tube Angle | 75.5 ° | 74.5 ° | 73.5 ° | 73 ° | 72.5 ° | 72 ° |
| Seat Tube Length | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 70 ° | 70.75 ° | 71.5 ° | 72 ° | 72.5 ° | 73 ° |
| Head Tube Length | 110 mm | 125 mm | 140 mm | 155 mm | 170 mm | 195 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1031 mm | 1032 mm | 1033 mm | 1037 mm | 1043 mm | 1052 mm |
| Bottom Bracket Drop | 71 mm | 71 mm | 69 mm | 69 mm | 67 mm | 67 mm |
| Standover Height | 753 mm | 775 mm | 793 mm | 810 mm | 828 mm | 854 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 161 cm | 166 cm | 172 cm | 178 cm | 183 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm | 181 cm | 186 cm | 191 cm |
Model Overview
Tricross Expert Double is part of the Specialized Tricross model. Specialized released 27 bikes variations of this model so far. Check out the entire range from 2009 of this model, by clicking this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Touring bikes average price
According to our calculations, the average cost of a Touring bike that is reliable is 1007$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Touring bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Overview of components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The Tricross Expert Double 2009 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Tricross Expert Double has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
Sizes
There are 6 sizes available for this model. Rider height can be anywhere between 155 cm – 191 cm (5.09 ft – 6.27 ft). In short, you can easily find one that suits you.
