Specialized Turbo Levo Hardtail 2022
2022 E-bike
Estimate price |
2,846$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork Suntour XCM
-
Groupset Alivio -
Suspension Hardtail -
Motor Specialized 250W 50Nm mid-drive -
Battery Specialized M1-400, integrated Trail Display, ANT+/Bluetooth® module, 400Wh -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Specialized M5 Aluminum, 29 Trail HT Geometry, integrated down tube battery, enclosed internal cable, Command Post routing, 148mm spacing
Suspension Fork
SR Suntour XCM32, 47mm offset, 15x110mm thru-axle, 100mm travel
Drivetrain
Rear Derailleur
Shimano Alivio, SGS, 9-speed
Shift Levers
Shimano Alivio, 9-speed w/ Optical Gear Display
Cassette
Shimano HG201, 9-speed, 11-36t
Crank
Custom alloy forged crankarms
Chain
KMC e9S.NPBK, e-bike chain, 9-speed w/ Missing Link™
Pedals
Specialized Body Geometry Fitness, platform, plastic
Wheels
Front Hub
Specialized, sealed cartridge bearings, 15x110mm spacing, 28h
Rear Hub
Specialized, sealed cartridge bearings, 12x148mm thru-axle, 32h
Rims
Front: Hand-built wheel assembly, Rear: Hand-built wheel assembly
Spokes
Stainless, 14g
Tires
Front: Ground Control, GRID casing, GRIPTON® compound, 2Bliss Ready, 29x2.3", Rear: Ground Control, GRID casing, GRIPTON® compound, 2Bliss Ready, 29x2.3"
Brakes
Brakes
Front: Shimano BR-MT200, hydraulic disc, 180mm, Rear: Shimano BR-MT200, hydraulic disc, 180mm
Cockpit
Stem
Specialized, 3D-forged alloy, 4-bolt, 6-degree rise, 31.8mm clamp
Handlebar
Specialized Trail, 6061 alloy, 8-degree backsweep, 6-degree upsweep, 27mm rise, 31.8mm clamp, S 720mm, M-XL 750mm
Grips
Specialized Body Geometry XC, clamp-on
Seat
Saddle
Body Geometry Myth 155 XS, Body Geometry Henge 143 S/M/L/XL, steel rails
Seatpost
Specialized 2-bolt head, forged alloy, 8mm offset, micro-adjust, 30.9mm
Motor & Battery
Motor
Specialized 1.2 E, custom Rx Street-tuned motor, 250W nominal
Battery
Specialized M1-400, integrated Trail Display, ANT+/Bluetooth® module, 400Wh
Charger
Custom Specialized 42V2A Charger w/ Rosenberger plug, AC power cord included
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.54 mm | 1.51 mm | 1.46 mm | 1.43 mm | 1.4 mm |
| Bottom Bracket Height | 308 mm | 308 mm | 308 mm | 308 mm | 308 mm |
| Front Center | 677 mm | 696 mm | 719 mm | 745 mm | 768 mm |
| Rake | 54 mm | 54 mm | 55 mm | 55 mm | 54 mm |
| Trail | 100 mm | 100 mm | 99 mm | 99 mm | 100 mm |
| Stack | 605 mm | 614 mm | 623 mm | 637 mm | 651 mm |
| Reach | 392 mm | 407 mm | 427 mm | 447 mm | 465 mm |
| Top Tube Length | 575 mm | 581 mm | 615 mm | 640 mm | 662 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 390 mm | 394 mm | 434 mm | 470 mm | 505 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 100 mm | 110 mm | 100 mm | 115 mm | 130 mm |
| Chainstay Length | 457 mm | 457 mm | 457 mm | 457 mm | 457 mm |
| Wheelbase | 1128 mm | 1147 mm | 1171 mm | 1197 mm | 1220 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm |
| Standover Height | 695 mm | 763 mm | 793 mm | 819 mm | 845 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Turbo Levo Hardtail belongs to the Specialized E Turbo Levo model. Specialized released 86 e-bikes variations of this model so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
Specialized Turbo Levo Hardtail 2022 is the most affordable e-bike of this model and has a price of 2841$. On the other hand, Specialized S-Works Turbo Levo 2022, is the most expensive and costs 13522$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Crosscountry e-bikes average price
If you want to purchase a solid Crosscountry e-bike, it is important to know that the average cost is 2453$. However, you could also get a good Crosscountry e-bike even if you pay a lower amount than the average price. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 2841$. If we compare this with the average Crosscountry e-bike cost we notice that the price is 15.82% higher.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork
The Suntour XCM is included from the factory. It has a travel distance of 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
When leaving the production line, the Turbo Levo Hardtail model has 29″ aluminum wheels. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Turbo Levo Hardtail comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, you can easily find one that suits you.
