Specialized Turbo Vado 6.0 Step-Through 2023
2023 E-bike
Estimate price |
6,308$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 50mm -
Fork Suntour NCX
-
Groupset XT, SLX -
Suspension Hardtail -
Motor Specialized 250W 72Nm mid-drive -
Battery Specialized U1-600, On/Off button, state of charge display, 600Wh -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
E5 Aluminum, bottom bracket motor mount, Fitness/Transportation Geometry, fully integrated & lockable down tube battery, internal cable routing, fender/rack mounts, Smooth Welds
Suspension Fork
SR Suntour NCX E25, alloy steerer, 15mm thru-axle, 44mm offset, 50mm of travel
Drivetrain
Rear Derailleur
Shimano XT, Shadow Plus, GS cage, 11-speed
Shift Levers
Shimano SLX, 11-speed
Cassette
Shimano SLX, 11-speed, 11-42t
Crank
Custom alloy forged crankarms, 40T
Chain
Shimano HG601, 11spd
Pedals
Specialized Commuter w/ grip tape & reflectors
Wheels
Front Hub
Specialized front hub disc, sealed bearings, 15x100mm thru-axle, 32h
Rear Hub
Specialized, sealed cartridge bearings, 12x148mm thru-axle, 32h
Rims
Double-wall alloy, 27mm internal width, 28h
Spokes
DT Swiss Industry
Tires
Front: Electrak 2.0 Armadillo, 700x51c, Rear: Electrak 2.0 Armadillo, 700x51c
Brakes
Brakes
Front: TRP Zurich, hydraulic 4-piston disc, 180mm, Rear: TRP Zurich, hydraulic 4-piston disc, 180mm
Cockpit
Stem
Specialized Stealth Stem, alloy, 14 deg, 31.8mm, integrated TCD mount
Handlebar
Specialized, alloy, 9-degree backsweep, 4-degree upsweep, 680mm width, 31.8mm
Grips
Body Geometry Women's XC Contour
Seat
Saddle
Bridge Sport, hollow cr-mo rails, 155mm
Seatpost
Specialized Alloy, Single Bolt, 30.9mm
Motor & Battery
Motor
Specialized 1.2 S, custom Rx Street-tuned motor, 250W nominal
Battery
Specialized U1-600, On/Off button, state of charge display, 600Wh
Charger
Custom charger, 42V4A w/ Rosenberger plug, 100-240V
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.563 mm | 1.557 mm | 1.47 mm | 1.478 mm |
| Front Center | 647 mm | 658 mm | 683 mm | 704 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 86 mm | 86 mm | 86 mm | 86 mm |
| Stack | 619 mm | 629 mm | 629 mm | 652 mm |
| Reach | 396 mm | 404 mm | 428 mm | 441 mm |
| Seat Tube Length | 400 mm | 450 mm | 485 mm | 535 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 145 mm | 145 mm | 155 mm | 170 mm |
| Chainstay Length | 478 mm | 478 mm | 478 mm | 478 mm |
| Wheelbase | 1116 mm | 1127 mm | 1152 mm | 1173 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 715 mm | 720 mm | 727 mm | 744 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Turbo Vado 6.0 Step-Through belongs to the Specialized E Turbo Vado model. Specialized released 78 e-bikes variations of this model so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
The most economical model, the Specialized Turbo Vado 3.0 2023 has a starting price of 3250$. Specialized Turbo Vado 6.0 Step-Through 2023 on the other hand is the most expensive at 5840$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Hybrid e-bikes average price
According to our math, the average price for a trustworthy Hybrid e-bike is 2480$. However, this doesn’t mean that if you spend less money on a Hybrid e-bike, you couldn’t get a decent one. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
This e-bike was released in 2023 and its price was 5840$. Doing a quick comparison, we notice that Turbo Vado 6.0 Step-Through price is 135.48% more expensive than the average cost of a Hybrid e-bike.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork
The fork installed on this bike is the Suntour NCX model. The travel on this model is 50mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Fork material
When it comes to the fork, this e-bike has an aluminum one, so there won’t be much extra weight added to the e-bike. However, they are not so stiff as carbon forks are.
Wheels
The wheels on Turbo Vado 6.0 Step-Through are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Specialized Turbo Vado 6.0 Step-Through has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
Turbo Vado 6.0 Step-Through comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
