Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset RED -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Sizing
Recommended size guide.
49cm
155cm - 163cm
52cm
161cm - 169cm
54cm
166cm - 175cm
56cm
172cm - 181cm
58cm
178cm - 186cm
61cm
183cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
FACT 10r carbon, FACT IS construction, aero tube shape, compact race design, tapered 1-1/8"" to 1-3/8"" head tube, internal cable routing, carbon OSBB
Suspension Fork
Venge Pro FACT carbon, full monocoque, OS race for 1-3/8"" bearing
Drivetrain
Rear Derailleur
SRAM Red
Front Derailleur
SRAM Red
Shift Levers
SRAM Red DoubleTap, 10-speed
Cassette
SRAM 1070, 10-speed, 11-28t
Crank
Specialized Pro FACT carbon
Bottom Bracket
OS integrated, sealed bearings
Chain
KMC X10 SL nickel plate
Pedals
Nylon flat test ride, loose ball, w/ reflectors
Wheels
Rims
Roval Rapide EL 45
Tires
Specialized Turbo Pro w/ BlackBelt, aramid bead, 127 TPI, 700x23c
Brakes
Brakes
SRAM Force
Brake Levers
SRAM Red
Cockpit
Stem
New Specialized ProSet 7075, cone head bolt and plastic clip, 12-degree, 4-degree shim, 31.8mm
Handlebar
New Specialized Tarmac Expert, alloy
Headset
1-1/8"" upper and 1-3/8"" lower Cr-Mo cartridge bearings, w/ custom integrated top cap
Seat
Saddle
Body Geometry Romin Evo Expert w/ hollow ti rails
Seatpost
Venge Aero, FACT carbon, flippable 20/0mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.32 mm | 1.37 mm | 1.41 mm | 1.43 mm | 1.48 mm | 1.51 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 267 mm | 267 mm | 268 mm | 268 mm |
| Front Center | 576 mm | 576 mm | 583 mm | 590 mm | 605 mm | 612 mm |
| Rake | 45 mm | 45 mm | 45 mm | 43 mm | 43 mm | 43 mm |
| Trail | 62 mm | 57 mm | 57 mm | 56 mm | 56 mm | 53 mm |
| Stack | 505 mm | 527 mm | 543 mm | 565 mm | 592 mm | 613 mm |
| Reach | 384 mm | 384 mm | 385 mm | 394 mm | 400 mm | 406 mm |
| Top Tube Length | 517 mm | 536 mm | 547 mm | 564 mm | 581 mm | 599 mm |
| Seat Tube Angle | 75.5 ° | 74 ° | 73.5 ° | 73.25 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 467 mm | 487 mm | 507 mm | 527 mm | 547 mm | 577 mm |
| Head Tube Angle | 72.25 ° | 73 ° | 73 ° | 73.5 ° | 73.5 ° | 74 ° |
| Head Tube Length | 100 mm | 120 mm | 140 mm | 160 mm | 190 mm | 210 mm |
| Chainstay Length | 404 mm | 404 mm | 404 mm | 404 mm | 406 mm | 409 mm |
| Wheelbase | 969 mm | 969 mm | 977 mm | 985 mm | 1002 mm | 1012 mm |
| Bottom Bracket Drop | 71 mm | 71 mm | 69 mm | 69 mm | 67 mm | 67 mm |
| Standover Height | 740 mm | 765 mm | 788 mm | 808 mm | 833 mm | 859 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 161 cm | 166 cm | 172 cm | 178 cm | 183 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm | 181 cm | 186 cm | 191 cm |
Model Overview
Venge Pro SRAM RED Mid-Compact completes the Specialized Venge model. Specialized launched 62 bikes of this model so far. You can easily view all of the Specialized Venge bikes models from 2012, here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Aero bikes
According to our math, the average price for a trustworthy Aero bike is 4211$. However, you could also get a good Aero bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Venge Pro SRAM RED Mid-Compact components
Fork material
The fork on this bike is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
The wheels on Venge Pro SRAM RED Mid-Compact are the 700c carbon type. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Venge Pro SRAM RED Mid-Compact comes with Rim brakes. Rim brakes deliver an average performance overall. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
This bike is available in 6 sizes. They vary from 155 cm – 191 cm (5.09 ft – 6.27 ft). In conclusion, you won’t have a problem finding one that suits you.
