Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Altus, Shimano -
Suspension Rigid -
Drivetrain 3 × 7 -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Globe A1 Premium Aluminum commuting design, fully manipulated custom tubing w/ fender and rack braze-ons, integrated kickstand mount
Suspension Fork
Globe Vienna straight-blade steel fork
Drivetrain
Rear Derailleur
Shimano Altus, 7-speed
Front Derailleur
Shimano FD-C051BM, 31.8mm clamp, top swing, dual pull
Shift Levers
Shimano, ST-EF-50, 7-speed, EZ fire plus
Cassette
Shimano MF-TZ31-7, 7-speed, 13-34t Mega Range
Crank
SR-Suntour 7-speed crankset, square, fully riveted plastic spider, w/ chainguard
Bottom Bracket
Cartridge bearing, square spindle with crank stop right side and capless bolts
Chain
KMC Z7 w/ reuseable Missing Link
Pedals
Globe City, Body Geometry, composite w/rubber top, 1.5mm varus wedge
Wheels
Front Hub
Forged alloy, double sealed, ground race, QR, 32h
Rear Hub
Forged alloy, double sealed, ground race, freewheel type, QR, 32h
Rims
700c, single wall, 32h
Spokes
2mm (14g) stainless
Tires
Specialized Nimbus, 700x35c, 60TPI, w/ Flak Jacket protection
Brakes
Brakes
Alloy linear pull, 1pc. pad
Brake Levers
Shimano (integrated w/ shifter)
Cockpit
Stem
Forged alloy, 2-bolt, 15 degree rise, 25.4mm clamp
Handlebar
Alloy riser bar, 25.4mm, 25mm rise, 620mm wide, 8 degree back sweep, 8 degree up
Headset
1-1/8"" threadless, integrated, semi-cartridge campy style bearings
Seat
Saddle
Specialized Body Geometry Fitness, 143mm width, front and rear bumpers
Seatpost
Alloy, 2-bolt forged head, 12.5mm offset, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Front Center | 637 mm | 648 mm | 654 mm | 659 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 78 mm | 78 mm | 74 mm | 71 mm |
| Top Tube Length | 552 mm | 567 mm | 582 mm | 597 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 385 mm | 435 mm | 485 mm | 535 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 70 ° | 70.5 ° |
| Head Tube Length | 126 mm | 146 mm | 166 mm | 186 mm |
| Chainstay Length | 457 mm | 457 mm | 457 mm | 457 mm |
| Wheelbase | 1086 mm | 1097 mm | 1103 mm | 1108 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 721 mm | 757 mm | 794 mm | 831 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Vienna 1 is part of the Specialized Vienna model. 11 bikes variations carry this model name so far. You can easily view all of the Specialized Vienna bikes models from 2010, here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Commuter bikes
If you want an acceptable Commuter bike you should know that the average price is 762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Commuter bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Vienna 1 components
Fork material
When it comes to the fork, this bike has a steel one, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels
The wheels on Vienna 1 are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Vienna 1 has Rim brakes. Rim brakes deliver an average performance overall. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
