Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Alivio, Altus -
Suspension Rigid -
Drivetrain 3 × 8 -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Globe A1 Premium Aluminum commuting design, fully manipulated custom tubing w/ fender and rack braze-ons, integrated kickstand mount
Suspension Fork
Globe Vienna straight-blade aluminum fork
Drivetrain
Rear Derailleur
Shimano Alivio, 8-speed
Front Derailleur
Shimano FD-M310, 31.8mm clamp, top swing, dual pull
Shift Levers
Shimano SL-MC40, 8-speed, Rapid Fire
Cassette
SRAM PG-820, 8-speed, 11-32t
Crank
Shimano FC-M361-8 w/ chainguard
Bottom Bracket
Cartridge bearing, square spindle with crank stop right side and capless bolts
Chain
KMC Z8, w/ reusable Missing Link
Pedals
Globe City, Body Geometry, composite w/rubber top, 1.5mm varus wedge
Wheels
Front Hub
Forged alloy, double sealed, ground race, QR, 32h
Rear Hub
Forged alloy, double sealed, ground race, cassette, QR, 32h
Rims
Globe 700c, double wall, 32h w/CNC side wall
Spokes
1.8mm (15g) stainless
Tires
Specialized Nimbus, 700x35c, 60TPI, w/ Flak Jacket protection
Brakes
Brakes
Alloy linear pull, 1pc. pad
Brake Levers
V-Brake, linear pull
Cockpit
Stem
Forged alloy, 2-bolt, 25.4mm, 10 degree rise
Handlebar
Alloy riser bar, 25.4mm, 25mm rise, 620mm wide, 8 degree back sweep, 8 degree up
Headset
1-1/8"" threadless, integrated, semi-cartridge campy style bearings
Seat
Saddle
Specialized BG Sonoma, 155mm width
Seatpost
Alloy, 2-bolt forged head, 12.5mm offset, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Front Center | 637 mm | 648 mm | 654 mm | 659 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 78 mm | 78 mm | 74 mm | 71 mm |
| Top Tube Length | 552 mm | 567 mm | 582 mm | 597 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 385 mm | 435 mm | 485 mm | 535 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 70 ° | 70.5 ° |
| Head Tube Length | 126 mm | 146 mm | 166 mm | 186 mm |
| Chainstay Length | 457 mm | 457 mm | 457 mm | 457 mm |
| Wheelbase | 1086 mm | 1097 mm | 1103 mm | 1108 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 721 mm | 757 mm | 794 mm | 831 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Vienna 3 is a Specialized Vienna model. Specialized launched 11 bikes of this model so far. You can easily view all of the Specialized Vienna bikes models from 2010, here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Commuter bikes
According to our calculations, the average cost of a Commuter bike that is reliable is 762$. However, even if your budget is less than the average, you might still be able to get a top-quality Commuter bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork material
Vienna 3 has an aluminum fork, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels size
When it comes to wheels, the Vienna 3 bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Vienna 3 has Rim brakes. Rim brakes deliver an average performance overall. However, they are not nearly as effective as hydraulic brakes are.
Sizes
Specialized Vienna 3 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
