Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Shimano -
Suspension Rigid -
Drivetrain Internally Geared Hub -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Globe A1 Premium Aluminum trekking design, fully manipulated tubing, internal gear dropouts w/ fender and rack braze-ons
Suspension Fork
Globe A1 Premium Aluminum steerer and blades
Drivetrain
Shift Levers
Shimano Revo Twist shifter, 8-speed
Cassette
See rear hub
Crank
Globe single speed design
Bottom Bracket
FSA BB-7420, cartrdge bearings, 68mm x 122.5mm for 47.5mm chain line
Chain
Shimano 1/2 x 1/8""
Pedals
Globe, Body Geometry, anti-slip composite
Wheels
Front Hub
Shimano HD-3N30-QR super low resistance dynamo hub, 32h
Rear Hub
Shimano Nexus Internal 8-speed, 32h
Rims
Specialized/Alex Globe, 700c, 32h, double wall w/ machine sidewalls and eyelets
Spokes
1.8mm (15g) stainless
Tires
Specialized Infinity, 700x38c, 60TPI, Flak Jacket, Reflex strips
Brakes
Brakes
Alloy linear pull
Brake Levers
Shimano BL-42 for Revo shifter
Cockpit
Stem
Globe forged alloy, 15 degree rise
Handlebar
Globe alloy flat bar, 25.4mm, 600mm wide, 27 degree back sweep
Grips
Body Geometry Comfort w/ integrated bell, 132mm
Headset
Specialized 1 1/8"" threadless, semi integrated, Campy style
Seat
Saddle
Specialized Sonoma Sport, 155mm width
Seatpost
Specialized alloy, no offset, two bolt head, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 45cm | 49cm | 53cm | 57cm | 61cm |
|---|---|---|---|---|---|
| Front Center | 642 mm | 657 mm | 667 mm | 666 mm | 687 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 82 mm | 82 mm | 82 mm | 75 mm | 68 mm |
| Top Tube Length | 552 mm | 567 mm | 582 mm | 597 mm | 637 mm |
| Seat Tube Angle | 76 ° | 75.5 ° | 74.5 ° | 73.5 ° | 72.5 ° |
| Seat Tube Length | 385 mm | 425 mm | 490 mm | 520 mm | 560 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 70 ° | 71 ° |
| Head Tube Length | 150 mm | 170 mm | 190 mm | 210 mm | 230 mm |
| Chainstay Length | 457 mm | 457 mm | 457 mm | 457 mm | 457 mm |
| Wheelbase | 1091 mm | 1101 mm | 1111 mm | 1110 mm | 1131 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 717 mm | 758 mm | 779 mm | 799 mm | 823 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
Vienna Deluxe 3 is part of the Specialized Vienna model. There are 11 bikes that carry this model name. Check out the entire range from 2009 of this model, by clicking this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Commuter bikes average price
According to our math, the average price for a trustworthy Commuter bike is 762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Commuter bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Vienna Deluxe 3 components
Fork material
When it comes to the fork, this bike has an aluminum one, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels
When it comes to wheels, the Vienna Deluxe 3 bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Specialized Vienna Deluxe 3 is equipped with Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, you could spend a little extra and get a bike that has hydraulic brakes.
