Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 27.5" -
Travel Front 140mm -
Fork RockShox Pike Select
-
Groupset SX Eagle -
Suspension Hardtail -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Steel
Suspension Fork
RockShox Pike Select
Rear Shock
None
Drivetrain
Rear Derailleur
SRAM SX Eagle, 12-speed
Front Derailleur
None
Shift Levers
SRAM SX Eagle, 12-speed
Cassette
SRAM SX Eagle, 12-speed, 11-50 tooth
Crank
SRAM SX Eagle
Bottom Bracket
73mm
Chain
SRAM SX Eagle, 12-speed
Chain Guide
None
Pedals
None
Wheels
Front Hub
Stanton-branded Novatec
Rear Hub
Stanton-branded Novatec
Rims
WTB i29
Tires
Front: WTB Vigilante, 27.5" x 2.5", Rear: WTB Trail Boss, 27.5" x 2.4"
Brakes
Brakes
SRAM Level, 2-piston
Brake Levers
SRAM Level
Cockpit
Stem
Stanton
Handlebar
Stanton
Grips
Stanton
Headset
Stanton
Seat
Saddle
Stanton
Seatpost
RockShox Reverb Stealth dropper, 175mm drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16.5" | 18" |
|---|---|---|
| Stack Reach Ratio | 1.33 mm | 1.29 mm |
| Bottom Bracket Height | 312 mm | 312 mm |
| Front Center | 750 mm | 776 mm |
| Rake | 38 mm | 38 mm |
| Trail | 124 mm | 124 mm |
| Stack | 600.13 mm | 609.19 mm |
| Reach | 451.25 mm | 473.48 mm |
| Top Tube Length | 613 mm | 638 mm |
| Seat Tube Angle | 73 ° | 73 ° |
| Seat Tube Length | 420 mm | 457 mm |
| Head Tube Angle | 65 ° | 65 ° |
| Head Tube Length | 110 mm | 120 mm |
| Chainstay Length | 418 mm | 418 mm |
| Wheelbase | 1164 mm | 1190 mm |
| Bottom Bracket Drop | 43 mm | 43 mm |
| Wheels | 27" | 27" |
Model Overview
Switchback 631 Gen 3 Standard is a Stanton Switchback model. Stanton launched 5 bikes of this model so far. You can easily view all of the Stanton Switchback bikes models from 2021, here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Overview of components
Fork
Stanton Switchback 631 Gen 3 Standard 2021 bike is equipped with the RockShox Pike Select fork, and has 140mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
When leaving the production line, the Switchback 631 Gen 3 Standard model has 27.5″ aluminum wheels. These wheels will provide you with more control over the bike. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Switchback 631 Gen 3 Standard has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Dropper post
Stanton Switchback 631 Gen 3 Standard includes a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
