Stevens 3X Gent 2023
2023 Road
Estimate price |
871$
Weight | 13.5 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Fork Suntour NEX -
Groupset Alivio, Altus -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium 6061, O.L.D.: 135 mm, Brake: cantilever, BB: BSA 73 mm, Front derailleur mount: clamp, Cable routing: external, Fender + rack mounts
Suspension Fork
SR Suntour NEX-P, Travel: 63 mm, Coil spring, Steerer 1 1/8", O.L.D.: 100 mm, Brake: cantilever
Drivetrain
Rear Derailleur
Shimano Alivio Trekking, RD-T4000-SGS, 8/9-speed, Total capacity: 45 T
Front Derailleur
Shimano Altus, FD-M310-M6, 3-speed
Shift Levers
Shimano ST-EF500, 3-speed, 2 finger
Cassette
Shimano CS-HG31, 8-speed, Combination: 11-13-15-17-20-23-26-30 T
Crank
Shimano Tourney, FC-TX801, 48-38-28 T, BB type: BSA 73mm / 2-Piece
Bottom Bracket
BSA, 73mm, threaded
Chain
KMC Z8.3
Pedals
MTB Alu Flatpedal Reflex
Wheels
Front Hub
Shimano HB-T3000, Axle: QR9x100 mm
Rear Hub
Shimano FH-T3000, Axle: QR10x135 mm
Rims
Oxygen COMP A17, ETRTO: 17 x 622
Tires
Schwalbe Smart Sam Active-Line, Tire size: 42-622, SBC compound, KevlarGuard
Brakes
Brakes
Tektro STB-01, V-Brake
Cockpit
Stem
Oxygen Driver, Handlebar clamp: 31.8 mm, Angle: 17°
Handlebar
Oxygen Driver, Width: 640 mm, Backsweep: 9°, Rise: 12 mm, Clamp: 31.8 mm
Headset
STEVENS MTB 1 1/8", Upper bearing cup: ZS44/28.6, Lower bearing cup: ZS44/30
Seat
Saddle
Oxygen Raceline
Seatpost
Oxygen Aluminium, Length: 250 mm, Diameter: 27.2 mm, Insertion depth: min. 80 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 52cm | 55cm | 58cm | 61cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.53 mm | 1.54 mm | 1.58 mm | 1.63 mm |
| Bottom Bracket Height | 295 mm | 295 mm | 295 mm | 295 mm | 295 mm |
| Front Center | 615 mm | 613 mm | 625 mm | 630 mm | 638 mm |
| Rake | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm |
| Trail | 83 mm | 81 mm | 77 mm | 75 mm | 71 mm |
| Stack | 571 mm | 601 mm | 622 mm | 643 mm | 662 mm |
| Reach | 400 mm | 393 mm | 403 mm | 407 mm | 406 mm |
| Top Tube Length | 574 mm | 582 mm | 598 mm | 614 mm | 622 mm |
| Seat Tube Angle | 73 ° | 72.5 ° | 72.5 ° | 72 ° | 72 ° |
| Seat Tube Length | 423 mm | 458 mm | 488 mm | 517 mm | 548 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71.5 ° | 72 ° | 72 ° |
| Head Tube Length | 100 mm | 130 mm | 150 mm | 170 mm | 190 mm |
| Chainstay Length | 451 mm | 451 mm | 451 mm | 451 mm | 451 mm |
| Wheelbase | 1060 mm | 1058 mm | 1070 mm | 1075 mm | 1083 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm |
| Standover Height | 768 mm | 802 mm | 823 mm | 848 mm | 873 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
About this model
3X Gent completes the Stevens 3x model. There are 4 bikes that carry this model name. You can easily view all of the Stevens 3x bikes models from 2023, here.
Model range prices
Stevens 3X Lady 2023 is the most affordable bike of this model and has a price of 793$. On the other hand, Stevens 3X Gent 2023, is the most expensive and costs 793$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Cyclocross bikes
According to our calculations, the average cost of a Cyclocross bike that is reliable is 2012$. However, even though the average price of a Cyclocross bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2023 for 793$. If we compare this with the average Cyclocross bike cost we notice that the price is 153.72% lower.
Average weight for Cyclocross bikes
On a deeper look, we notice that the average weight of a Cyclocross bike is 8.79 kg (19.38 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
With a weight of 13.5 kg (29.76 lbs), Stevens bike is much heavier than average. In other words, this model is 53.58% heavier than the average Cyclocross bike.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
3X Gent components
Fork
Stevens 3X Gent 2023 bike is equipped with the Suntour NEX fork, and has mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
The wheels on 3X Gent are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Stevens 3X Gent has Rim brakes installed. Rim brakes deliver an average performance overall. However, they are not nearly as effective as hydraulic brakes are.
