Stevens E-14 Forma 2023
2023 E-bike
Estimate price |
8,028$
Weight | 28.7 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork Suntour MOBIE
-
Suspension Hardtail -
Motor Bosch 250W 85Nm mid-drive -
Battery Bosch PowerTube 625, Capacity: 625 Wh/16.7 Ah, Voltage: 36 V, Technology: Li-Ion -
Drivetrain Belt Drive -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium 6061, O.L.D.: 135 mm, Brake: postmount disc 7", BB: Bosch, Cable routing: internal, Fender + rack mounts, Adjustable dropouts, Carrying handle, PowerTube box (lockable)
Suspension Fork
SR Suntour Mobie25-Air LOR, Travel: 63 mm, Air suspension, Lockout, Tapered Steerer 1 1/8" - 1 1/2", O.L.D.: 100 mm, Brake: postmount disc 6", Fender mounts
Drivetrain
Shift Levers
Rohloff E-14 E-Shifter
Cassette
Gates CDX Center Track sprocket, 19 T, Rohloff mount
Crank
Oxygen E-Scorpo, BB type: Bosch / ISIS, Chainguard
Bottom Bracket
Bosch, press-fit
Pedals
ATB Alu Pro Reflex
Wheels
Front Hub
Shimano Deore XT, HB-M8010, Axle: QR15x100 mm
Rims
Oxygen RM-26 Disc SL, ETRTO: 26 x 622
Tires
Schwalbe Marathon E-Plus Performance, Tire size: 50-622, ADDIX E compound, SmartGuard, Reflective stripes
Brakes
Brakes
Tektro HD-T737, Hydraulic disc brake, 4 pistons
Brake Levers
Tektro HD-T737, 3 finger
Cockpit
Stem
Oxygen Versa II, adjustable, Handlebar clamp: 31.8 mm, Angle: adjustable (0° - 90°)
Handlebar
Oxygen E-Scorpo, Width: 680 mm, Backsweep: 5°, Rise: 25 mm, Clamp: 31.8 mm
Headset
STEVENS AH Taper 1 1/8"-1 1/2", Upper bearing cup: ZS44/28.6, Lower bearing cup: ZS55/40
Seat
Saddle
Selle Royal ON Female
Seatpost
Oxygen E-Scorpo DPR-S-E, Travel: 75 mm | 100 mm, Suspension Seatpost, Remote Lockout, Length: 360 mm | 410 mm, Diameter: 30.9 mm, Insertion depth: 100 mm
Motor & Battery
Motor
Bosch G4 Performance Line CX, Continuous rated power: 250 W, Max. torque: 85 Nm, Breakaway at 25 km/h (15.5 mph), No of notches: 4 drive modes with support levels 60-340 % plus walk assistance, Mileage: See BOSCH Range Assistant
Battery
Bosch PowerTube 625, Capacity: 625 Wh/16.7 Ah, Voltage: 36 V, Technology: Li-Ion
Charger
Bosch 4A charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 52cm | 56cm |
|---|---|---|---|
| Stack Reach Ratio | 1.65 mm | 1.62 mm | 1.61 mm |
| Bottom Bracket Height | 298 mm | 298 mm | 298 mm |
| Front Center | 672 mm | 685 mm | 706 mm |
| Rake | 44 mm | 44 mm | 44 mm |
| Trail | 90 mm | 80 mm | 80 mm |
| Stack | 644 mm | 670 mm | 689 mm |
| Reach | 390 mm | 413 mm | 427 mm |
| Top Tube Length | 588 mm | 618 mm | 638 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 160 mm | 160 mm | 160 mm |
| Head Tube Angle | 68.5 ° | 70 ° | 70 ° |
| Head Tube Length | 170 mm | 190 mm | 210 mm |
| Chainstay Length | 485 mm | 485 mm | 485 mm |
| Wheelbase | 1149 mm | 1163 mm | 1184 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm |
| Standover Height | 472 mm | 470 mm | 469 mm |
| Wheels | 700 | 700 | 700 |
About this model
E-14 Forma is a Stevens E E 14 model. 4 e-bikes variations carry this model name so far. Take a sneak peek at all Stevens E E 14 e-bikes models from 2023, by clicking here.
Model range prices
The most economical model, the Stevens E-14 Gent 2023 has a starting price of 7094$. Stevens E-14 Forma 2023 on the other hand is the most expensive at 7411$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
General Urban e-bikes average price
Our math shows that the average cost of a dependable General Urban e-bike is 2098$. However, paying less money than this amount doesn’t mean that you couldn’t get a great General Urban e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
This e-bike was released in 2023 and its price was 7411$. Comparing the average cost of a General Urban e-bike to this one, you will see that E-14 Forma price is 253.24% more expensive.
General Urban e-bikes average weight
General Urban e-bikes weigh an average of 24.08 kg (53.09 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Weighing 28.7 kg (63.27 lbs), the E-14 Forma model is much heavier than average. In conclusion, the average General Urban e-bike weighs 19.19% less than E-14 Forma.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
E-14 Forma components
Fork
The E-14 Forma comes factory-installed with the Suntour MOBIE fork. This has a travel range of 63mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
As for the wheels, Stevens E-14 Forma 2023, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Stevens E-14 Forma is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
