Stevens E-4X Tour Lady 2022
2022 E-bike
Estimate price |
3,325$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork Suntour MOBIE
-
Groupset Alivio -
Suspension Hardtail -
Motor Bosch 250W 50Nm mid-drive -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium 6061 TB, O.L.D.: 135 mm, Brake: Postmount disc 7", BB: Bosch, Cable routing: internal, Fender + rack mounts
Suspension Fork
SR Suntour Mobie25 LOR, Travel: 63 mm, Coil spring, Lockout, Tapered Steerer 1 1/8" - 1 1/2", O.L.D.: 100 mm, Brake: postmount disc 6"
Drivetrain
Shift Levers
Shimano Alivio, SL-M3100, 9-speed
Cassette
Shimano CS-HG400-9, 9-speed, Combination: 11-13-15-17-20-23-26-30-36 T
Crank
Oxygen E-Scorpo, BB type: Bosch / ISIS, Chainguard
Bottom Bracket
Bosch, press-fit
Chain
Shimano CN-HG53
Pedals
MTB Alu Flatpedal Reflex
Wheels
Rims
Oxygen RM-T20 Disc, ETRTO: 20 x 622
Tires
Continental Double Fighter III, Tire size: 50-622, Reflective stripes
Brakes
Brakes
Shimano BR-MT200, Hydraulic disc brake
Brake Levers
Shimano BL-MT200, 3 finger
Cockpit
Stem
Oxygen E-Scorpo, Handlebar clamp: 31.8 mm, Angle: 17°
Handlebar
Oxygen E-Scorpo, Width: 700 mm, Backsweep: 9°, Rise: 25 mm, Clamp: 31.8 mm
Headset
STEVENS AH Taper 1 1/8"-1 1/2", Upper bearing cup: ZS44/28.6, Lower bearing cup: ZS55/40
Seat
Saddle
Oxygen Lynx
Seatpost
Oxygen E-Scorpo, Length: 320 mm, Diameter: 30,9 mm, Insertion depth: min. 100 mm
Motor & Battery
Motor
Bosch G3 Active Line Plus Cruise, Continuous rated power: 250 W, Max. torque: 50 Nm, Breakaway at 25 km/h (15.5 mph), Mileage: See BOSCH Range Assistant, No of notches: 4 drive modes with support levels 40-270 % plus walk assistance
Remote
Bosch Purion
Charger
Bosch 2A charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 50cm | 54cm | Measuring mode |
|---|---|---|---|---|
| Stack Reach Ratio | 1.604 mm | 1.615 mm | 1.61 mm | mm |
| Bottom Bracket Height | 321 mm | 321 mm | 321 mm | mm |
| Front Center | 633 mm | 649 mm | 668 mm | mm |
| Rake | 42 mm | 42 mm | 42 mm | mm |
| Trail | 79 mm | 78 mm | 79 mm | mm |
| Stack | 619 mm | 638 mm | 657 mm | mm |
| Reach | 386 mm | 395 mm | 408 mm | mm |
| Top Tube Length | 575 mm | 590 mm | 609 mm | mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | ° |
| Seat Tube Length | 289 mm | 271 mm | 285 mm | mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | ° |
| Head Tube Length | 140 mm | 160 mm | 180 mm | mm |
| Chainstay Length | 485 mm | 485 mm | 485 mm | mm |
| Wheelbase | 1112 mm | 1129 mm | 1148 mm | mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm | mm |
| Standover Height | 726 mm | 717 mm | 730 mm | mm |
| Wheels | 700 | 700 | 700 | 700 |
Model Overview
E-4X Tour Lady is part of the Stevens E E 4x model. Stevens released 2 e-bikes variations of this model so far. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
Stevens E-4X Tour Lady 2022 is the most economical model, with a starting price of 3078$. Stevens E-4X Tour Gent 2022 on the other hand costs 3078$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Commuter e-bikes
According to our calculations, the average cost of a Commuter e-bike that is reliable is 2569$. However, even though the average price of a Commuter e-bike is lower, you might still be able to get a top-quality e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
This e-bike was released in 2022 and its price was 3078$. If we compare this with the average Commuter e-bike cost we notice that the price is 19.81% more expensive.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
E-4X Tour Lady components
Fork
This e-bike has the Suntour MOBIE fork installed. The fork’s travel is 63mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
When leaving the production line, the E-4X Tour Lady model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The E-4X Tour Lady comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
