Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 160mm -
Travel Rear 150mm -
Fork Fox Performance Elite Float 36
-
Groupset XT -
Suspension Full -
Motor Shimano 250W 70Nm mid-drive -
Battery Shimano STEPS E8010, 36V, lithium-ion, 14Ah, with ABUS lock -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
FOX FLOAT 36 Performance Elite E-Bike+, 51mm offset
Rear Shock
FOX FLOAT DPX2 Performance Elite E-Bike, 185mm x 55mm, trunnion mount
Drivetrain
Rear Derailleur
Shimano Deore XT M8100, 12-speed, SHADOW RD+, SGS cage
Front Derailleur
N/A
Shift Levers
Shimano Deore XT M8100, 12-speed, I-SPEC-EV clamp
Cassette
Shimano Deore XT M8100, 12-speed, 10-51 tooth
Crank
Shimano Deore XT STEPS M8050, HOLLOWTECH, 170mm length
Bottom Bracket
BSA, 73mm, threaded
Chain
Shimano Deore XT M8100, 12-speed
Chain Guide
e*thirteen upper slider
Pedals
MTB Alu Flatpedal Reflex
Wheels
Front Hub
Shimano Deore XT, CENTER LOCK rotor mounts, 15x110mm Boost front, 12x148mm Boost rear
Rear Hub
Shimano Deore XT, CENTER LOCK rotor mounts, 15x110mm Boost front, 12x148mm Boost rear
Rims
SUNringlé Duroc TR35
Tires
Schwalbe Eddy Current, Evolution, foldable, Addix Soft compound, tubeless easy, 27.5" x 2.6"
Brakes
Brakes
Shimano Deore XT M8120, 4-piston, Shimano MT800 203mm CENTER LOCK rotors
Brake Levers
Shimano Deore XT M8100
Cockpit
Stem
Oxygen E-Scorpo, 31.8mm bar clamp, 6° rise, 50mm length (16"/18"/20"), 60mm length (22")
Handlebar
Oxygen E-Scorpo, 760mm width, 9° backsweep, 25mm rise, 31.8mm clamp diameter
Headset
Stevens MTB Taper, ZS44/28.6 upper, ZS55/40 lower
Seat
Saddle
Oxygen Roccia
Seatpost
KS LEV-SI dropper, 100mm/125mm/150mm drop
Motor & Battery
Motor
Shimano STEPS E8000, 250W, 70Nm torque
Battery
Shimano STEPS E8010, 36V, lithium-ion, 14Ah, with ABUS lock
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 20" | 22" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.454 mm | 1.411 mm | 1.366 mm | 1.341 mm |
| Bottom Bracket Height | 342 mm | 342 mm | 342 mm | 342 mm |
| Stack | 602 mm | 611 mm | 620 mm | 629 mm |
| Reach | 414 mm | 433 mm | 454 mm | 469 mm |
| Top Tube Length | 577 mm | 600 mm | 622 mm | 640 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 400 mm | 430 mm | 460 mm | 490 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 95 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 436 mm | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1174 mm | 1196 mm | 1219 mm | 1239 mm |
| Bottom Bracket Drop | 13 mm | 13 mm | 13 mm | 13 mm |
| Standover Height | 726 mm | 741 mm | 751 mm | 763 mm |
| Wheels | 27" | 27" | 27" | 27" |
About this model
E-Sledge ES is part of the Stevens E E Sledge model. 3 e-bikes variations carry this model name so far. You can get a glimpse at all models from 2020, by clicking on this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Enduro e-bikes
According to our calculations, the average cost of an Enduro e-bike that is reliable is 4785$. However, you could also get a good Enduro e-bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
Enduro e-bikes average weight
If we make a quick analysis of the average weight of an Enduro e-bike, we get 23.42 kg (51.63 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Stevens E-Sledge ES it’s weighing 22.5 kg (49.6 lbs). At this weight, is slightly lighter than average. To sum up, it’s 4.09% lighter than the average weight of Enduro e-bikes.
E-Sledge ES components
Fork
The Fox Performance Elite Float 36 is included from the factory. It has a travel distance of 160mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The E-Sledge ES has a rear shock with a travel of 150mm. The model FOX FLOAT DPX2 Performance Elite E-Bike is the one installed in this e-bike. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
When it comes to wheels, the E-Sledge ES e-bike is equipped with the 27.5″ aluminum model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Dropper post
The Stevens model is also equipped with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
