Stevens E-Triton 5.5.1 Forma 2023
2023 E-bike
Estimate price |
4,357$
Weight | 25.9 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork Suntour NCX
-
Groupset SunRace MS, Deore -
Suspension Hardtail -
Motor Bosch 250W 75Nm mid-drive -
Battery Bosch PowerPack 545, Capacity: 545 Wh/14.4 Ah, Voltage: 36 V, Technology: Li-Ion -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium 6061, O.L.D.: 135 mm, Brake: postmount disc 6", BB: Bosch, Cable routing: internal, Fender + rack mounts, Carrying handle
Suspension Fork
SR Suntour NCX-D Air LO, Travel: 63 mm, Air suspension, Lockout, Tapered Steerer 1 1/8" - 1 1/2", O.L.D.: 100 mm, Brake: postmount disc 6", Fender mounts
Drivetrain
Rear Derailleur
Sunrace RDMS103, 10-speed, Total capacity: 42 T
Shift Levers
Shimano Deore, SL-M6000, 10-speed
Cassette
SunRace CSMX3, 10-speed, Combination: 11-13-15-18-21-24-28-32-37-42 T
Crank
Oxygen E-Scorpo, BB type: Bosch / ISIS
Bottom Bracket
Bosch, press-fit
Chain
KMC X10eS EPT
Pedals
ATB Alu Pro Reflex
Wheels
Front Hub
Shimano Deore XT, HB-M8010, Axle: QR15x100 mm
Rear Hub
Shimano Deore XT, FH-M8000, 10-speed, Axle: QR10x135 mm
Rims
Oxygen RM-26 Disc SL, ETRTO: 26 x 622
Tires
Schwalbe Marathon, Tire size: 47-622, Endurance compound, GreenGuard, Reflective stripes
Brakes
Brakes
Tektro Volans, HD-T532-F, Hydraulic disc brake, 4 pistons
Brake Levers
Tektro HD-T532, 3 finger
Cockpit
Stem
Oxygen Versa II, adjustable, Handlebar clamp: 31.8 mm, Angle: adjustable (0° - 90°)
Handlebar
Oxygen E-Scorpo, Width: 680 mm, Backsweep: 5°, Rise: 25 mm, Clamp: 31.8 mm
Headset
STEVENS AH Taper 1 1/8"-1 1/2", Upper bearing cup: ZS44/28.6, Lower bearing cup: ZS55/40
Seat
Saddle
Selle Royal ON Female
Seatpost
Oxygen E-Scorpo, Length: 320 mm, Diameter: 30,9 mm, Insertion depth: min. 100 mm
Motor & Battery
Motor
Bosch G3 Performance Line, Continuous rated power: 250 W, Max. torque: 75 Nm, Breakaway at 25 km/h (15.5 mph), No of notches: 4 drive modes with support levels 60-340 % plus walk assistance, Mileage: See BOSCH Range Assistant
Battery
Bosch PowerPack 545, Capacity: 545 Wh/14.4 Ah, Voltage: 36 V, Technology: Li-Ion
Charger
Bosch 4A charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 52cm | 56cm |
|---|---|---|---|
| Stack Reach Ratio | 1.65 mm | 1.62 mm | 1.61 mm |
| Bottom Bracket Height | 295 mm | 295 mm | 295 mm |
| Front Center | 672 mm | 685 mm | 706 mm |
| Rake | 44 mm | 44 mm | 44 mm |
| Trail | 89 mm | 80 mm | 80 mm |
| Stack | 645 mm | 671 mm | 690 mm |
| Reach | 391 mm | 414 mm | 428 mm |
| Top Tube Length | 589 mm | 619 mm | 639 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 229 mm | 229 mm | 330 mm |
| Head Tube Angle | 68.5 ° | 70 ° | 70 ° |
| Head Tube Length | 170 mm | 190 mm | 210 mm |
| Chainstay Length | 497 mm | 497 mm | 497 mm |
| Wheelbase | 1162 mm | 1175 mm | 1196 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm |
| Standover Height | 467 mm | 476 mm | 476 mm |
| Wheels | 700 | 700 | 700 |
About this model
E-Triton 5.5.1 Forma is a Stevens E E Triton model. Stevens launched 27 e-bikes of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Stevens E-Triton Forma 2023 is the most affordable e-bike of this model and has a price of 3917$. On the other hand, Stevens E-Triton 9.7.1 Plus Gent 2023, is the most expensive and costs 5823$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Commuter e-bikes
According to our calculations, the average cost of a Commuter e-bike that is reliable is 2569$. However, even if your budget is less than the average, you might still be able to get a top-quality Commuter e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
When Stevens released this model in 2023, its price was 4023$. Comparing the average cost of a Commuter e-bike to this one, you will see that E-Triton 5.5.1 Forma price is 56.6% more expensive.
Average weight for Commuter e-bikes
Commuter e-bikes weigh an average of 25.2 kg (55.56 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
With a weight of 25.9 kg (57.1 lbs), Stevens e-bike is slightly heavier than average. In short, the average Commuter e-bike weight is 2.78% lower than this one.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork
This e-bike has the Suntour NCX fork installed. The fork’s travel is 63mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
When leaving the production line, the E-Triton 5.5.1 Forma model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The E-Triton 5.5.1 Forma comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
