Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 140mm -
Travel Rear 130mm -
Fork Fox Performance Elite Float 34
-
Groupset XT -
Suspension Full -
Motor Shimano 250W 70Nm mid-drive -
Battery Shimano STEPS E8010, 36V, lithium-ion, 14Ah, with ABUS lock -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
FOX FLOAT 34 Performance Elite E-Bike+, 51mm offset
Rear Shock
FOX FLOAT DPX2 Performance Elite E-Bike, 185mm x 50mm, trunnion mount
Drivetrain
Rear Derailleur
Shimano Deore XT M8100, 12-speed, SHADOW RD+, SGS cage
Front Derailleur
N/A
Shift Levers
Shimano Deore XT M8100, 12-speed, I-SPEC-EV clamp
Cassette
Shimano Deore XT M8100, 12-speed, 10-51 tooth
Crank
Shimano Deore XT STEPS M8050, HOLLOWTECH, 170mm length
Bottom Bracket
BSA, 73mm, threaded
Chain
Shimano Deore XT M8100, 12-speed
Chain Guide
e*thirteen upper slider
Pedals
MTB Alu Flatpedal Reflex
Wheels
Front Hub
Shimano Deore XT, CENTER LOCK rotor mounts, 15x110mm Boost front, 12x148mm Boost rear
Rear Hub
Shimano Deore XT, CENTER LOCK rotor mounts, 15x110mm Boost front, 12x148mm Boost rear
Rims
SUNringlé Duroc TR35
Tires
Schwalbe Eddy Current, Evolution, foldable, Addix Soft compound, tubeless easy, 27.5" x 2.6"
Brakes
Brakes
Shimano Deore XT M8120, 4-piston, Shimano MT800 203mm CENTER LOCK rotors
Brake Levers
Shimano Deore XT M8100
Cockpit
Stem
Oxygen E-Scorpo, 31.8mm bar clamp, 6° rise, 50mm length (16"/18"/20"), 60mm length (22")
Handlebar
Oxygen E-Scorpo, 760mm width, 9° backsweep, 25mm rise, 31.8mm clamp diameter
Headset
Stevens MTB Taper, ZS44/28.6 upper, ZS55/40 lower
Seat
Saddle
Oxygen Roccia
Seatpost
KS LEV-SI dropper, 100mm/125mm/150mm drop
Motor & Battery
Motor
Shimano STEPS E8000, 250W, 70Nm torque
Battery
Shimano STEPS E8010, 36V, lithium-ion, 14Ah, with ABUS lock
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 20" | 22" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.409 mm | 1.363 mm | 1.319 mm | 1.289 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm | 335 mm |
| Stack | 596 mm | 604 mm | 612 mm | 620 mm |
| Reach | 423 mm | 443 mm | 464 mm | 481 mm |
| Top Tube Length | 572 mm | 596 mm | 619 mm | 637 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 400 mm | 430 mm | 460 mm | 490 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 95 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 436 mm | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1162 mm | 1186 mm | 1207 mm | 1225 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm | 20 mm |
| Standover Height | 714 mm | 727 mm | 739 mm | 750 mm |
| Wheels | 27" | 27" | 27" | 27" |
Model Overview
E-Whaka ES belongs to the Stevens E E Whaka model. There are 3 e-bikes that carry this model name. Take a sneak peek at all Stevens E E Whaka e-bikes models from 2020, by clicking here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail e-bikes average price
Our math shows that the average cost of a dependable Trail e-bike is 3365$. However, even though the average price of a Trail e-bike is lower, you might still be able to get a top-quality e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Trail e-bikes average weight
Trail e-bikes have an average weight of 23.7 kg (52.25 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
E-Whaka ES weighs 22.3 kg (49.16 lbs) and is a bit lighter than the average. In short, the average Trail e-bike weight is 6.28% higher than this one.
E-Whaka ES components
Fork
The fork installed on this bike is the Fox Performance Elite Float 34 model. The travel on this model is 140mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The shock that’s installed on this e-bike is FOX FLOAT DPX2 Performance Elite E-Bike, with a travel distance of 130mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
The wheels on E-Whaka ES are the 27.5″ aluminum type. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Dropper post
A dropper post is included with the E-Whaka ES. Therefore, climbing or descending will be a breeze.
