Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Travel Rear 120mm -
Fork Fox Performance Float 34
-
Groupset XT -
Suspension Full -
Drivetrain 2 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
FOX FLOAT 34 Performance Step-Cast, remote lockout, 44mm offset (27.5"), 51mm offset (29")
Rear Shock
FOX FLOAT DPS Performance Elite, remote lockout, 190mm x 51mm
Drivetrain
Rear Derailleur
Shimano Deore XT M8120, 12-speed, SGS cage, SHADOW RD+
Front Derailleur
Shimano Deore XT M8020, side-swing
Shift Levers
Shimano Deore XT M8100, 12-speed, I-SPEC EV clamp
Cassette
Shimano Deore XT M8100, 12-speed, 10-45 tooth
Crank
Shimano Deore XT M8120, HOLLOWTECH II, 170mm length (16"), 175mm length (18"/20"/22")
Bottom Bracket
Shimano, BB92 press-fit
Chain
Shimano Deore XT M8100, 12-speed
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
Fulcrum Red Metal 500 DB wheelset, CENTER LOCK rotor mounts, 110x15mm Boost front, 148x12mm Boost rear
Rear Hub
Fulcrum Red Metal 500 DB wheelset, CENTER LOCK rotor mounts, 110x15mm Boost front, 148x12mm Boost rear
Rims
Fulcrum Red Metal 500 DB wheelset, 27.5" (16"), 29" (18"/20"/22")
Spokes
Fulcrum Red Metal 500 DB wheelset
Tires
Schwalbe Nobby Nic, Evolution, foldable, Addix Speedgrip compound, SnakeSkin protection, tubeless easy, 2.35"
Brakes
Brakes
Shimano Deore XT M8100, Shimano RT70 180mm CENTER LOCK rotors
Brake Levers
Shimano Deore XT M8100
Cockpit
Stem
Oxygen Scorpo MTB, 31.8mm bar clamp, 5° rise, Length: 70mm (16"), 80mm (18"/20"), 90mm (22")
Handlebar
Oxygen Scorpo MTB, 760mm width, 7° backsweep, 11mm rise, 31.8mm clamp diameter
Headset
Stevens MTB Taper, ZS44/28.6 upper, ZS55/40 lower
Seat
Saddle
Oxygen Roccia
Seatpost
KS LEV-SI dropper, 100mm/125mm/150mm drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 20" | 22" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.37 mm | 1.34 mm | 1.38 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm | 335 mm |
| Stack | 565 mm | 591 mm | 601 mm | 630 mm |
| Reach | 420 mm | 431 mm | 448 mm | 458 mm |
| Top Tube Length | 576 mm | 596 mm | 616 mm | 636 mm |
| Seat Tube Angle | 74 ° | 73.8 ° | 73.6 ° | 73.4 ° |
| Seat Tube Length | 430 mm | 455 mm | 500 mm | 530 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 100 mm | 100 mm | 110 mm | 140 mm |
| Chainstay Length | 426 mm | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1115 mm | 1151 mm | 1171 mm | 1192 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm | 20 mm |
| Standover Height | 757 mm | 769 mm | 774 mm | 776 mm |
| Wheels | 27" | 27" | 27" | 27" |
About this model
Jura ES belongs to the Stevens Jura model. Stevens launched 4 bikes of this model so far. You can easily view all of the Stevens Jura bikes models from 2020, here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Trail bikes average weight
Trail bikes weigh an average of 12.98 kg (28.62 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Stevens Jura ES it’s weighing 13.4 kg (29.54 lbs). At this weight, is slightly heavier than average. To sum up, it’s 3.24% heavier than the average weight of Trail bikes.
Jura ES components
Fork
The Jura ES comes factory-installed with the Fox Performance Float 34 fork. This has a travel range of 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The Jura ES has a rear shock with a travel of 120mm. The model FOX FLOAT DPS Performance Elite is the one installed in this bike. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
The Jura ES 2020 bike is equipped with 27.5″ aluminum wheels when leaving the factory. The 27.5″ wheels are a great choice for smaller riders. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Stevens Jura ES is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Dropper post
A dropper post is included with the Jura ES. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
