Stevens Sonora 2023
2023 Mountain
Estimate price |
2,637$
Weight | 11.8 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork RockShox SID
-
Groupset SX Eagle, NX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon SL HMF, O.L.D.: 148 mm, Brake: postmount disc 6", BB: Pressfit BB92, Cable routing: internal, Cable routing: internal
Suspension Fork
Rock Shox SID SL, Travel: 100 mm, Air suspension, Tapered Steerer 1 1/8" - 1.5", O.L.D.: 110 mm, Brake: postmount disc 6"
Drivetrain
Rear Derailleur
SRAM SX Eagle, RD-SX-1-B1, 12-speed, Cage Lock™, X-Actuation™, Total capacity: 40 T
Shift Levers
SRAM NX Eagle Trigger, 12-speed
Cassette
SRAM PG 1210 Eagle, 12-speed, Combination: 11-13-15-17-19-22-25-28-32-36-42-50 T
Crank
SRAM SX Eagle B DUB, 34 T, BB type: Press Fit MTB 89/92 mm / 24 mm, Boost chain line
Bottom Bracket
BB86/BB92, press-fit
Chain
SRAM SX Eagle
Wheels
Front Hub
Strummer CLTP, Axle: QR15x110 mm
Rear Hub
Shimano FH-MT400-B, Axle: QR12x148 mm
Rims
Oxygen RM-26 Disc, ETRTO: 26 x 622
Tires
Schwalbe Racing Ray, Tire size: 57-622, Foldable, ADDIX compound, TwinSkin
Brakes
Brakes
SRAM Level T-A1, Hydraulic disc brake
Brake Levers
SRAM Level T, DirectLink™
Cockpit
Stem
Oxygen Scorpo MTB, Handlebar clamp: 31.8 mm, Angle: 5°
Handlebar
Oxygen Scorpo MTB, Width: 700 mm, Backsweep: 9°, Rise: 15 mm, Clamp: 31.8 mm
Headset
STEVENS MTB Taper 1 1/8"-1 1/2", Upper bearing cup: IS42/28.6, Lower bearing cup: IS52/40
Seat
Saddle
Oxygen Roccia
Seatpost
Oxygen Scorpo MTB, Length: 380 mm, Diameter: 30.9 mm, Insertion depth: min. 100 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 20" | 22" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.45 mm | 1.42 mm | 1.37 mm |
| Bottom Bracket Height | 310 mm | 310 mm | 310 mm | 310 mm |
| Front Center | 659 mm | 685 mm | 711 mm | 737 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 86 mm | 85 mm | 86 mm | 86 mm |
| Stack | 603 mm | 608 mm | 623 mm | 633 mm |
| Reach | 396 mm | 419 mm | 440 mm | 463 mm |
| Top Tube Length | 573 mm | 598 mm | 623 mm | 648 mm |
| Seat Tube Angle | 73.7 ° | 73.7 ° | 73.7 ° | 73.7 ° |
| Seat Tube Length | 347 mm | 393 mm | 432 mm | 472 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 95 mm | 100 mm | 115 mm | 125 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1085 mm | 1111 mm | 1137 mm | 1163 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 745 mm | 777 mm | 804 mm | 833 mm |
| Wheels | 29" | 29" | 29" | 29" |
Model Overview
Sonora belongs to the Stevens Sonora model. There are 12 bikes that carry this model name. Take a sneak peek at all Stevens Sonora bikes models from 2023, by clicking here.
Model range prices
Stevens Sonora 2023 is the cheapest bike model and costs 2434$. Stevens Sonora GX AXS 2023 is the most expensive one and costs 4235$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Crosscountry bikes
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Stevens Sonora price was 2434$. Doing a quick comparison, we notice that Sonora price is 27.77% higher than the average cost of a Crosscountry bike.
Average weight for Crosscountry bikes
Crosscountry bikes weigh an average of 12.4 kg (27.34 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Sonora weighs 11.8 kg (26.01 lbs) and is a bit lighter than the average. In short, the average Crosscountry bike weight is 5.08% higher than this one.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork
The Sonora comes factory-installed with the RockShox SID fork. This has a travel range of 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
The wheels on Sonora are the 29″ aluminum type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Sonora comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
