Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork Fox Performance Float 32
-
Groupset X01 Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
FOX FLOAT 32 Performance Step-Cast, remote lockout, 44mm offset
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM X01 Eagle, 12-speed, Type-3 Roller Bearing Clutch, Cage Lock
Front Derailleur
N/A
Shift Levers
SRAM X01 Eagle, 12-speed, trigger
Cassette
SRAM XG1275 Eagle, 12-speed, 10-50 tooth
Crank
SRAM X01 Eagle Carbon DUB, 170mm length (16"), 175mm length (18"/20"/22")
Bottom Bracket
SRAM DUB PressFit
Chain
SRAM X01 Eagle, 12-speed
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
DT Swiss X1900 Spline wheelset, CENTER LOCK rotor mounts, 110x15mm Boost front, 148x12mm Boost rear
Rear Hub
DT Swiss X1900 Spline wheelset, CENTER LOCK rotor mounts, 110x15mm Boost front, 148x12mm Boost rear
Rims
DT Swiss X1900 Spline wheelset
Spokes
DT Swiss X1900 Spline wheelset
Tires
Front: Schwalbe Racing Ray, foldable, Addix Speed compound, SnakeSkin protection, 29" x 2.25", Rear: Schwalbe Racing Ralph, Evolution, foldable, Addix Speed compound, SnakeSkin protection, 29" x 2.25"
Brakes
Brakes
Shimano Deore XT M8100, Shimano MT800 CENTER LOCK rotors (180mm front, 160mm rear)
Brake Levers
Shimano Deore XT M8100
Cockpit
Stem
Oxygen Scorpo MTB, 31.8mm bar clamp, 5° rise, Length: 70mm (16"), 80mm (18"), 90mm (20"), 100mm (22")
Handlebar
Oxygen Scorpo MTB, 700mm width, 7° backsweep, 11mm rise, 31.8mm clamp diameter
Headset
Stevens Race Taper, IS42/28.6 upper, IS52/40 lower
Seat
Saddle
Oxygen Roccia
Seatpost
Oxygen Scorpo MTB, 380mm length
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 20" | 22" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.42 mm | 1.38 mm | 1.34 mm |
| Bottom Bracket Height | 306 mm | 306 mm | 306 mm | 306 mm |
| Stack | 597 mm | 602 mm | 616 mm | 625 mm |
| Reach | 401 mm | 424 mm | 445 mm | 468 mm |
| Top Tube Length | 569 mm | 594 mm | 619 mm | 644 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 396 mm | 420 mm | 480 mm | 520 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 95 mm | 100 mm | 115 mm | 125 mm |
| Chainstay Length | 431 mm | 431 mm | 431 mm | 431 mm |
| Wheelbase | 1071 mm | 1096 mm | 1123 mm | 1148 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm |
| Standover Height | 730 mm | 762 mm | 791 mm | 822 mm |
| Wheels | 29" | 29" | 29" | 29" |
About this model
Sonora XO completes the Stevens Sonora model. 9 bikes variations carry this model name so far. You can get a glimpse at all models from 2020, by clicking on this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Crosscountry bikes
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Crosscountry bikes average weight
The average weight for Crosscountry bikes is 12.4 kg (27.34 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Stevens Sonora XO it’s weighing 10.1 kg (22.27 lbs). At this weight, is much lighter than average. In other words, this model is 22.77% lighter than the average Crosscountry bike.
Overview of components
Fork
The Sonora XO comes factory-installed with the Fox Performance Float 32 fork. This has a travel range of 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
The wheels on Sonora XO are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
When you want to stop the bike in time, the brakes are vital. The Sonora XO has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
