Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Altus, Shimano -
Suspension Rigid -
Motor Shimano 250W 40Nm mid-drive -
Battery SHIMANO STEPS, BT-E8014, 36V, 418Wh, frame mount -
Drivetrain 1 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
LG
180cm - 191cm
XL
189cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alloy 6061 Double Butted, Sport eMTB Geometry, Smooth Welding, SHIMANO STEPS ready, Semi integrated battery, Inner Cable Routing, IDK dropout
Suspension Fork
eRX 610 28", Alloy/hi-ten rigid, Ahead 1-1/8", QR Type
Drivetrain
Shift Levers
SHIMANO ALTUS SL-M315-8R RapidFire Plus, 8-speed
Cassette
SHIMANO CS-HG31-8, 11-34T
Crank
SHIMANO FC-E5010, 38T
Bottom Bracket
STEPS, press-fit
Chain
KMC X8
Pedals
Marwi SP-610
Wheels
Front Hub
SHIMANO HB-TX505, 32H, CENTER LOCK, QR Type
Rear Hub
SHIMANO FH-TX505-8, 32H, CENTER LOCK, M10x135mm, QR Type
Rims
Stars J20S, 32H
Spokes
Sapim Galvanized Black
Tires
Impac Dualpac, 28x1.75", Reflective tape
Brakes
Brakes
SHIMANO BL-MT200/BR-MT200, hydraulic disc brake
Cockpit
Stem
ONE1 Sport TDS-D507 Alloy, 31.8mm, +15°
Handlebar
ONE1 Alloy, MTB AL-325BT, 6° upsweep, 9° backsweep, 25mm rise, 660mm, 31.8mm
Grips
Velo VLG-1777D2
Seat
Saddle
Selle Royal Vivo HRN
Seatpost
ONE1 Sport Alloy, SP C207
Motor & Battery
Motor
SHIMANO STEPS E5000, 36V, 250W, 40Nm
Battery
SHIMANO STEPS, BT-E8014, 36V, 418Wh, frame mount
Charger
SHIMANO EC-E6002 1.8A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | LG | XL |
|---|---|---|
| Stack Reach Ratio | 1.57 mm | 1.56 mm |
| Bottom Bracket Height | 271 mm | 271 mm |
| Front Center | 660 mm | 682 mm |
| Rake | 45 mm | 45 mm |
| Trail | 74 mm | 74 mm |
| Stack | 628 mm | 647 mm |
| Reach | 401 mm | 416 mm |
| Top Tube Length | 588 mm | 608 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° |
| Seat Tube Length | 483 mm | 546 mm |
| Head Tube Angle | 70 ° | 70 ° |
| Head Tube Length | 140 mm | 160 mm |
| Chainstay Length | 448 mm | 448 mm |
| Wheelbase | 1100 mm | 1122 mm |
| Bottom Bracket Drop | 65 mm | 65 mm |
| Wheels | 700 | 700 |
| Rider Min Height | 180 cm | 189 cm |
| Rider Max Height | 191 cm | 200 cm |
Model Overview
eRX 610 TOURING belongs to the Superior E Erx model. There are 8 e-bikes that carry this model name. Check out the entire range from 2020 of this model, by clicking this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Touring e-bikes
Our math shows that the average cost of a dependable Touring e-bike is 2429$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Touring e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
Average weight for Touring e-bikes
Touring e-bikes have an average weight of 25.55 kg (56.33 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
eRX 610 TOURING weighs 22.3 kg (49.16 lbs) and is considerably lighter than the average. To sum up, it’s 14.57% lighter than the average weight of Touring e-bikes.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork material
eRX 610 TOURING has an aluminum fork, which doesn’t add too much extra weight to the e-bike. However, it is not so stiff as steel or carbon forks are.
Wheels
When it comes to wheels, the eRX 610 TOURING e-bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The eRX 610 TOURING comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
eRX 610 TOURING comes in 2 sizes, that range from 180 cm – 200 cm (5.91 ft – 6.56 ft). In conclusion, you won’t have a problem finding one that suits you.
