Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Fork SunTour NEX -
Groupset Deore, Shimano -
Suspension Hardtail -
Motor Shimano 250W 60Nm mid-drive -
Battery SHIMANO STEPS, BT-E8014, 36V, 418Wh, frame mount -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
LG
180cm - 191cm
XL
189cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alloy 6061 Double Butted, Sport eMTB Geometry, Smooth Welding, SHIMANO STEPS ready, Semi integrated battery, Inner Cable Routing, IDK dropout
Suspension Fork
SR Suntour NEX-E25DS, 1-1/8", Coil, QR Type, 63mm travel
Drivetrain
Rear Derailleur
SHIMANO DEORE RD-M6000 Shadow Plus
Shift Levers
SHIMANO DEORE SL-M6000-R RapidFire Plus, 10-speed
Cassette
SHIMANO CS-HG500-10, 11-42T
Crank
SHIMANO FC-E6100, 38T
Bottom Bracket
STEPS, press-fit
Chain
KMC e10S
Pedals
Marwi SP-610
Wheels
Front Hub
SHIMANO HB-TX505, 32H, CENTER LOCK, QR Type
Rear Hub
SHIMANO FH-TX505-8, 32H, CENTER LOCK, M10x135mm, QR Type
Rims
Stars J20S, 32H
Spokes
Sapim Galvanized Black
Tires
Schwalbe G-One Bite, 28x2.00", reflective tape
Brakes
Brakes
SHIMANO BL-MT200/BR-MT200, hydraulic disc brake
Cockpit
Stem
ONE1 Sport TDS-D507 Alloy, 31.8mm, -15°
Handlebar
ONE1 Alloy, MTB AL-325BT, 6° upsweep, 9° backsweep, 25mm rise, 660mm, 31.8mm
Grips
Velo VLG-1777D2
Seat
Saddle
Selle Royal Essenza Athletic
Seatpost
ONE1 Sport Alloy, SP C207
Motor & Battery
Motor
SHIMANO STEPS E6100, 36V, 250W, 60Nm
Battery
SHIMANO STEPS, BT-E8014, 36V, 418Wh, frame mount
Charger
SHIMANO EC-E6002 1.8A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | LG | XL |
|---|---|---|
| Stack Reach Ratio | 1.57 mm | 1.56 mm |
| Bottom Bracket Height | 271 mm | 271 mm |
| Front Center | 660 mm | 682 mm |
| Rake | 45 mm | 45 mm |
| Trail | 74 mm | 74 mm |
| Stack | 628 mm | 647 mm |
| Reach | 401 mm | 416 mm |
| Top Tube Length | 588 mm | 608 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° |
| Seat Tube Length | 483 mm | 546 mm |
| Head Tube Angle | 70 ° | 70 ° |
| Head Tube Length | 140 mm | 160 mm |
| Chainstay Length | 448 mm | 448 mm |
| Wheelbase | 1100 mm | 1122 mm |
| Bottom Bracket Drop | 65 mm | 65 mm |
| Wheels | 700 | 700 |
| Rider Min Height | 180 cm | 189 cm |
| Rider Max Height | 191 cm | 200 cm |
About this model
eRX 670 TOURING belongs to the Superior E Erx model. There are 8 e-bikes that carry this model name. Check out the entire range from 2020 of this model, by clicking this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Touring e-bikes
Our math shows that the average cost of a dependable Touring e-bike is 2429$. However, this doesn’t mean that if you spend less money on a Touring e-bike, you couldn’t get a decent one. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Touring e-bikes average weight
On a deeper look, we notice that the average weight of a Touring e-bike is 25.55 kg (56.33 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
considerably lighter than average, eRX 670 TOURING has a weight of 22.5 kg (49.6 lbs). In conclusion, the average Touring e-bike weighs 13.56% more than eRX 670 TOURING.
Internal Cable Routing
It’s also important to mention the internal cable routing that this e-bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork
Superior eRX 670 TOURING 2020 e-bike is equipped with the SunTour NEX fork, and has mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
As for the wheels, Superior eRX 670 TOURING 2020, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The eRX 670 TOURING comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
eRX 670 TOURING comes in 2 sizes, that range from 180 cm – 200 cm (5.91 ft – 6.56 ft). In conclusion, it won’t take much to find one that’s right for you.
