Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Fork RockShox Paragon Gold RL -
Groupset SLX, Shimano -
Suspension Hardtail -
Motor Shimano 250W 60Nm mid-drive -
Battery SHIMANO STEPS, BT-E8010, 36V, 504 Wh, frame mount -
Drivetrain 1 × 11 -
Brakes Rim
Sizing
Recommended size guide.
LG
180cm - 191cm
XL
189cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alloy 6061 Double Butted, Sport eMTB Geometry, Smooth Welding, SHIMANO STEPS ready, Semi integrated battery, Inner Cable Routing, IDK dropout
Suspension Fork
RockShox Paragon Gold RL, 1-1/8", Air, 65mm travel
Drivetrain
Rear Derailleur
SHIMANO SLX RD-M7000 Shadow Plus
Shift Levers
SHIMANO SLX SL-M7000-R RapidFire Plus, 11-speed
Cassette
SunRace CS-MS8-11, 11-46T
Crank
SHIMANO FC-E6100, 38T
Bottom Bracket
STEPS, press-fit
Chain
KMC e11T
Pedals
Marwi SP-610
Wheels
Front Hub
SHIMANO HB-TX505, 32H, CENTER LOCK, QR Type
Rear Hub
SHIMANO FH-TX505-8, 32H, CENTER LOCK, M10x135mm, QR Type
Rims
Stars J20S, 32H
Spokes
Sapim Leader, Stainless Black
Tires
Schwalbe G-One Bite, 28x2.00", reflective tape
Cockpit
Stem
ONE1 Sport TDS-D507 Alloy, 31.8mm, +15°
Handlebar
ONE1 Alloy, MTB AL-325BT, 6° upsweep, 9° backsweep, 25mm rise, 660mm, 31.8mm
Grips
Velo VLG-1777D2
Seat
Saddle
Selle Royal Essenza Athletic
Seatpost
ONE1 Sport Alloy, SP C207
Motor & Battery
Motor
SHIMANO STEPS E7000, 36V, 250W,60Nm
Battery
SHIMANO STEPS, BT-E8010, 36V, 504 Wh, frame mount
Charger
SHIMANO EC-E6002 1.8A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | LG | XL |
|---|---|---|
| Stack Reach Ratio | 1.57 mm | 1.56 mm |
| Bottom Bracket Height | 271 mm | 271 mm |
| Front Center | 660 mm | 682 mm |
| Rake | 45 mm | 45 mm |
| Trail | 74 mm | 74 mm |
| Stack | 628 mm | 647 mm |
| Reach | 401 mm | 416 mm |
| Top Tube Length | 588 mm | 608 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° |
| Seat Tube Length | 483 mm | 546 mm |
| Head Tube Angle | 70 ° | 70 ° |
| Head Tube Length | 140 mm | 160 mm |
| Chainstay Length | 448 mm | 448 mm |
| Wheelbase | 1100 mm | 1122 mm |
| Bottom Bracket Drop | 65 mm | 65 mm |
| Wheels | 700 | 700 |
| Rider Min Height | 180 cm | 189 cm |
| Rider Max Height | 191 cm | 200 cm |
About this model
eRX 690 TOURING is part of the Superior E Erx model. There are 8 e-bikes that carry this model name. You can get a glimpse at all models from 2020, by clicking on this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Touring e-bikes
According to our math, the average price for a trustworthy Touring e-bike is 2429$. However, you could also get a good Touring e-bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
Average weight for Touring e-bikes
Touring e-bikes have an average weight of 25.55 kg (56.33 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Superior eRX 690 TOURING it’s weighing 22.2 kg (48.94 lbs). At this weight, is much lighter than average. To sum up, it’s 15.09% lighter than the average weight of Touring e-bikes.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork
The RockShox Paragon Gold RL is included from the factory. It has a travel distance of mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
The wheels on eRX 690 TOURING are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Superior eRX 690 TOURING is equipped with Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they are not nearly as effective as hydraulic brakes are.
Sizes
eRX 690 TOURING comes in 2 sizes, that range from 180 cm – 200 cm (5.91 ft – 6.56 ft). In short, you can easily find one that suits you.
