Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork RST BLAZE
-
Groupset Alivio -
Suspension Hardtail -
Motor Bosch 250W 50Nm mid-drive -
Battery BOSCH PowerTube, 500Wh -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 171cm
MD
169cm - 180cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alu 6061 T6, Sport eMTB Geometry, Smooth Welding, Bosch system Powertube 625Wh battery ready, Inner Cable Routing
Suspension Fork
RST Blaze, 1-1/8", 100mm travel
Drivetrain
Rear Derailleur
SHIMANO ALIVIO RD-M3100, Shadow Design
Shift Levers
SHIMANO ALIVIO SL-M3100-R, RAPIDFIRE Plus, 9-speed
Cassette
SHIMANO CS-HG200, 9-speed, 11-36T
Crank
ONE Sport, Alloy
Bottom Bracket
Bosch, press-fit
Chain
KMC e9S
Pedals
Marwi SP-610
Wheels
Front Hub
SHIMANO HB-TX505, 32H, CL, M9X100mm, QR Type
Rear Hub
SHIMANO FH-TX505-8, 32H, CL, M10x135mm, QR Type
Rims
STARS J30D, Disc, 32H
Spokes
SAPIM Galvanized Black
Tires
Schwalbe Hurricane Performance, 29x2.25, ADDIX
Brakes
Brakes
SHIMANO MT200, hydraulic disc brake
Cockpit
Stem
ONE Sport, Alloy, 31.8mm, -8°°
Handlebar
ONE Alloy, 25mm rise, 660mm, 31.8mm
Headset
ACROS AZX-254, ZS44/28.6 - EC49/30; BlockLock
Seat
Saddle
Selle Royal Vivo
Seatpost
ONE Sport, Alloy, 30,9mm
Motor & Battery
Motor
BOSCH Active Line Plus, 50Nm
Battery
BOSCH PowerTube, 500Wh
Charger
BOSCH 2A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD |
|---|---|---|
| Stack Reach Ratio | 1.65 mm | 1.57 mm |
| Bottom Bracket Height | 314 mm | 314 mm |
| Front Center | 666 mm | 686 mm |
| Rake | 45 mm | 45 mm |
| Trail | 103 mm | 103 mm |
| Stack | 642 mm | 642 mm |
| Reach | 388 mm | 408 mm |
| Top Tube Length | 576 mm | 596 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° |
| Seat Tube Length | 406 mm | 457 mm |
| Head Tube Angle | 68 ° | 68 ° |
| Head Tube Length | 130 mm | 130 mm |
| Chainstay Length | 506 mm | 506 mm |
| Wheelbase | 1166 mm | 1186 mm |
| Bottom Bracket Drop | 60 mm | 60 mm |
| Wheels | 29" | 29" |
| Rider Min Height | 160 cm | 169 cm |
| Rider Max Height | 171 cm | 180 cm |
About this model
eXC 7019 WB completes the Superior E Exc model. Superior launched 18 e-bikes of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Superior eXC 7039 WB 2023 is the cheapest e-bike model and costs 3335$. Superior eXC 7039 B 2023 is the most expensive one and costs 3335$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Crosscountry e-bikes average price
If you want to purchase a solid Crosscountry e-bike, it is important to know that the average cost is 2453$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Internal Cable Routing
It’s also important to mention the internal cable routing that this e-bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork
The eXC 7019 WB comes factory-installed with the RST BLAZE fork. This has a travel range of 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
When leaving the production line, the eXC 7019 WB model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
When you want to stop the bike in time, the brakes are vital. The eXC 7019 WB has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
eXC 7019 WB comes in 2 sizes, that range from 160 cm – 180 cm (5.25 ft – 5.91 ft). In conclusion, it won’t take much to find one that’s right for you.
