Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork SunTour XCR
-
Groupset Deore -
Suspension Hardtail -
Motor Shimano 250W 60Nm mid-drive -
Battery DARFON, 36V, 504 Wh, integrated -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
170cm - 181cm
LG
179cm - 191cm
XL
189cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alu 6061 T6, Sport eMTB Geometry, Smooth Welding, SHIMANO STEPS ready, Integgrated 630Wh battery ready, Inner Cable Routing
Suspension Fork
SR Suntour XCR, 1-1/8", QR Type, Lockout, 100mm travel
Drivetrain
Rear Derailleur
SHIMANO DEORE RD-M4120 Shadow
Shift Levers
SHIMANO DEORE SL-M5100-R RapidFire Plus, 11-speed
Cassette
SHIMANO CS-M5100-11, 11-42T
Crank
ONE1 ET39-F13-SML-L/R, 38T
Bottom Bracket
STEPS, press-fit
Chain
KMC e11T
Pedals
Marwi SP-610
Wheels
Front Hub
SHIMANO HB-TX505, 32H, CENTER LOCK, QR Type
Rear Hub
SHIMANO FH-TX505-8, 32H, CENTER LOCK, M10x135mm, QR Type
Rims
Stars J30D, 32H
Spokes
Sapim Galvanized Black
Tires
Schwalbe Hurricane Performance, 29x2.25", ADDIX
Brakes
Brakes
SHIMANO BL-MT200/BR-MT200, hydraulic disc brake
Cockpit
Stem
ONE1 Sport MAS-D61248 Alloy, 31.8mm, -8°
Handlebar
ONE1 Alloy, MTB AL-325BT, 6° upsweep, 9° backsweep, 25mm rise, 720mm, 31.8mm
Grips
Velo VLG-1777D2
Seat
Saddle
Selle Royal Vivo HRN
Seatpost
ONE1 Sport Alloy, SP C207, 30.9mm
Motor & Battery
Motor
SHIMANO STEPS E7000, 36V, 250W, 60Nm
Battery
DARFON, 36V, 504 Wh, integrated
Remote
SHIMANO SC-E5000, Clamp band
Charger
DARFON 2A Smart Plus charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.59 mm | 1.51 mm | 1.45 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm |
| Front Center | 687 mm | 706 mm | 726 mm |
| Rake | 46 mm | 47 mm | 47 mm |
| Trail | 102 mm | 101 mm | 101 mm |
| Stack | 633 mm | 633 mm | 633 mm |
| Reach | 399 mm | 418 mm | 438 mm |
| Top Tube Length | 587 mm | 607 mm | 627 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 431 mm | 482 mm | 533 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 130 mm | 130 mm | 130 mm |
| Chainstay Length | 462 mm | 462 mm | 462 mm |
| Wheelbase | 1142 mm | 1162 mm | 1182 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 170 cm | 179 cm | 189 cm |
| Rider Max Height | 181 cm | 191 cm | 200 cm |
Model Overview
eXC 7039 is part of the Superior E Exc model. Superior released 14 e-bikes variations of this model so far. Take a sneak peek at all Superior E Exc e-bikes models from 2021, by clicking here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Crosscountry e-bikes
If you want to purchase a solid Crosscountry e-bike, it is important to know that the average cost is 2453$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Crosscountry e-bikes average weight
If we make a quick analysis of the average weight of a Crosscountry e-bike, we get 23.21 kg (51.17 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
With a weight of 22.1 kg (48.72 lbs), Superior e-bike is a bit lighter than average. In short, the average Crosscountry e-bike weight is 5.02% higher than this one.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork
The eXC 7039 comes factory-installed with the SunTour XCR fork. This has a travel range of 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
The wheels on eXC 7039 are the 29″ aluminum type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
eXC 7039 comes in 3 sizes, that range from 170 cm – 200 cm (5.58 ft – 6.56 ft). In conclusion, it won’t take much to find one that’s right for you.
