Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork SunTour XCR
-
Groupset Deore -
Suspension Hardtail -
Motor Shimano 250W 60Nm mid-drive -
Battery DARFON, 36V, 504 Wh, integrated -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 171cm
MD
169cm - 180cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alu 6061 T6, Woman eMTB Geometry, Smooth Welding, SHIMANO STEPS ready, Integgrated 630Wh battery ready, Inner Cable Routing
Suspension Fork
SR Suntour XCR, 1-1/8", QR Type, Lockout, 100mm travel
Drivetrain
Rear Derailleur
SHIMANO DEORE RD-M4120 Shadow
Shift Levers
SHIMANO DEORE SL-M5100-R RapidFire Plus, 11-speed
Cassette
SHIMANO CS-M5100-11, 11-42T
Crank
ONE1 ET39-F13-SML-L/R, 38T
Bottom Bracket
STEPS, press-fit
Chain
KMC e11T
Pedals
Marwi SP-610
Wheels
Front Hub
SHIMANO HB-TX505, 32H, CENTER LOCK, QR Type
Rear Hub
SHIMANO FH-TX505-8, 32H, CENTER LOCK, M10x135mm, QR Type
Rims
Stars J30D, 32H
Spokes
Sapim Galvanized Black
Tires
Schwalbe Hurricane Performance, 29x2.25", ADDIX
Brakes
Brakes
SHIMANO BL-MT200/BR-MT200, hydraulic disc brake
Cockpit
Stem
ONE1 Sport MAS-D61248 Alloy, 31.8mm, -8°
Handlebar
ONE1 Alloy, MTB AL-325BT, 6° upsweep, 9° backsweep, 25mm rise, 660mm, 31.8mm
Grips
Velo VLG-1777D2
Seat
Saddle
Selle Royal Vivo DRN
Seatpost
ONE1 Sport Alloy, SP C207, 30.9mm
Motor & Battery
Motor
SHIMANO STEPS E7000, 36V, 250W, 60Nm
Battery
DARFON, 36V, 504 Wh, integrated
Remote
SHIMANO SC-E5000, Clamp band
Charger
DARFON 2A Smart Plus charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD |
|---|---|---|
| Stack Reach Ratio | 1.66 mm | 1.58 mm |
| Bottom Bracket Height | 314 mm | 314 mm |
| Front Center | 667 mm | 687 mm |
| Rake | 47 mm | 47 mm |
| Trail | 101 mm | 101 mm |
| Stack | 642 mm | 642 mm |
| Reach | 387 mm | 407 mm |
| Top Tube Length | 576 mm | 596 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° |
| Seat Tube Length | 406 mm | 457 mm |
| Head Tube Angle | 68 ° | 68 ° |
| Head Tube Length | 130 mm | 130 mm |
| Chainstay Length | 471 mm | 471 mm |
| Wheelbase | 1131 mm | 1151 mm |
| Bottom Bracket Drop | 60 mm | 60 mm |
| Wheels | 29" | 29" |
| Rider Min Height | 160 cm | 169 cm |
| Rider Max Height | 171 cm | 180 cm |
About this model
eXC 7039 W is part of the Superior E Exc model. Superior launched 14 e-bikes of this model so far. Check out the entire range from 2021 of this model, by clicking this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Crosscountry e-bikes average price
According to our calculations, the average cost of a Crosscountry e-bike that is reliable is 2453$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Crosscountry e-bikes average weight
The average weight for Crosscountry e-bikes is 23.21 kg (51.17 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Superior eXC 7039 W it’s weighing 22 kg (48.5 lbs). At this weight, is a bit lighter than average. In conclusion, the average Crosscountry e-bike weighs 5.5% more than eXC 7039 W.
Internal Cable Routing
It’s also important to mention the internal cable routing that this e-bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
eXC 7039 W components
Fork
The SunTour XCR is included from the factory. It has a travel distance of 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
As for the wheels, Superior eXC 7039 W 2021, has a 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
Superior eXC 7039 W e-bike has 2 sizes, in the range of 160 cm – 180 cm (5.25 ft – 5.91 ft). In conclusion, it won’t take much to find one that’s right for you.
