Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Travel Rear 130mm -
Fork SunTour XCR 34
-
Groupset Deore, Shimano -
Suspension Full -
Motor Shimano 250W 60Nm mid-drive -
Battery DARFON, 36V, 504 Wh, integrated -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
170cm - 181cm
LG
179cm - 191cm
XL
189cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alu X6 Ultralite MTB Trail SUE03, Advanced e-MTB Geometry, Travel 130 mm, SHIMANO STEPS ready, NEW integrated battery, 3D alloy one piece link, Alloy swingarm, SR dropout, Boost 12x148 mm, Inner cable routing, Dropped seat post ready
Suspension Fork
SR Suntour XCR34 Air, 1-1/8", QR Type, Lockout, 140mm travel
Rear Shock
RockShox Deluxe Select Plus, remote Lockout, external rebound, 2 position compression (Open/Lock), size 210x50mm
Drivetrain
Rear Derailleur
SHIMANO DEORE RD-M6000 Shadow Plus
Shift Levers
SHIMANO DEORE SL-M6000-R RapidFire Plus, 10-speed
Cassette
SHIMANO CS-HG500-10, 11-42T
Crank
SHIMANO FC-E6100, 34T
Bottom Bracket
STEPS, press-fit
Chain
KMC e10S
Wheels
Front Hub
SHIMANO ALIVIO HB-MT400, 32H, CENTER LOCK, 15x110mm Thru Axle
Rear Hub
SHIMANO FH-MT400-B, 32H, CENTER LOCK, 12x148mm THRU Type AXLE
Rims
Stars J26S, 32H
Spokes
Sapim Galvanized Black
Tires
WTB Ranger Comp, 29x2.40"
Brakes
Brakes
TEKTRO HD-M735, hydraulic disc brake
Cockpit
Stem
ONE1 TDS-661 Alloy, 31.8mm, 0°
Handlebar
ONE1 Alloy, MTB AL-320BT, 3° upsweep, 9° backsweep, 20mm rise, 760mm, 31.8mm
Grips
ONE1 VLG-1661D2N, Lock-On
Seat
Saddle
Selle Royal Vivo HRN
Seatpost
ONE1 Race Alloy, SP 218, 30.9mm
Motor & Battery
Motor
SHIMANO STEPS E7000, 36V, 250W, 60Nm
Battery
DARFON, 36V, 504 Wh, integrated
Charger
DARFON 2A Smart charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.31 mm | 1.31 mm | 1.29 mm |
| Bottom Bracket Height | 354 mm | 354 mm | 354 mm |
| Front Center | 764 mm | 775 mm | 792 mm |
| Rake | 43 mm | 43 mm | 42 mm |
| Trail | 120 mm | 120 mm | 121 mm |
| Stack | 596 mm | 605 mm | 615 mm |
| Reach | 456 mm | 463 mm | 476 mm |
| Top Tube Length | 622 mm | 632 mm | 647 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 431 mm | 490 mm | 533 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1193 mm | 1204 mm | 1221 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 170 cm | 179 cm | 189 cm |
| Rider Max Height | 181 cm | 191 cm | 200 cm |
About this model
eXF 8069 completes the Superior E Exf model. Superior released 16 e-bikes variations of this model so far. Check out the entire range from 2020 of this model, by clicking this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Trail e-bikes average price
If you want to purchase a solid Trail e-bike, it is important to know that the average cost is 3365$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Average weight for Trail e-bikes
If we make a quick analysis of the average weight of a Trail e-bike, we get 23.7 kg (52.25 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Weighing 23.1 kg (50.93 lbs), the eXF 8069 model is slightly lighter than average. To sum up, it’s 2.6% lighter than the average weight of Trail e-bikes.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork
This e-bike has the SunTour XCR 34 fork installed. The fork’s travel is 140mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The eXF 8069 has a rear shock with a travel of 130mm. The model RockShox Deluxe Select Plus is the one installed in this e-bike. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
As for the wheels, Superior eXF 8069 2020, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
Nothing is more important on a bike than its ability to brake properly. Superior eXF 8069 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 170 cm – 200 cm (5.58 ft – 6.56 ft). In conclusion, finding one for you shouldn’t be a problem.
