Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Travel Rear 130mm -
Fork RockShox Recon Silver RL
-
Groupset SLX, Shimano -
Suspension Full -
Motor Shimano 250W 70Nm mid-drive -
Battery DARFON, 36V, 504 Wh, integrated -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
160cm - 170cm
LG
180cm - 191cm
XL
189cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alu X6 Ultralite MTB Trail SUE03, Advanced e-MTB Geometry, Travel 130 mm, SHIMANO STEPS ready, NEW integrated battery, 3D alloy one piece link, Alloy swingarm, SR dropout, Boost 12x148 mm, Inner cable routing, Dropped seat post ready
Suspension Fork
RockShox Recon RL, Tapered, SoloAir, 15x110mm axle, 140mm travel
Rear Shock
RockShox Deluxe Select Plus, remote Lockout, external rebound, 2 position compression (Open/Lock), size 210x50mm
Drivetrain
Rear Derailleur
SHIMANO SLX RD-M7000 Shadow Plus
Shift Levers
SHIMANO SLX SL-M7000-IR RapidFire Plus, 11-speed
Cassette
SunRace CS-MS8-11, 11-46T
Crank
SHIMANO FC-E8000, 34T
Bottom Bracket
STEPS, press-fit
Chain
KMC e11T
Wheels
Front Hub
SHIMANO ALIVIO HB-MT400, 32H, CENTER LOCK, 15x110mm Thru Axle
Rear Hub
SHIMANO FH-MT400-B, 32H, CENTER LOCK, 12x148mm THRU Type AXLE
Rims
Stars J26S, 32H
Spokes
Sapim Leader, Stainless Black
Tires
WTB Trail Boss TCS Light/Fast Rolling, 29x2.40"
Brakes
Brakes
TEKTRO HD-M745, hydraulic disc brake
Cockpit
Stem
ONE1 TDS-661 Alloy, 31.8mm, 0°
Handlebar
ONE1 Alloy, MTB AL-320BT, 3° upsweep, 9° backsweep, 20mm rise, 760mm, 31.8mm
Grips
ESI Chunky silicone grips
Seat
Saddle
fizik Taiga
Seatpost
ONE1 Alloy, MT171, dropper post, 30.9mm
Motor & Battery
Motor
SHIMANO STEPS E8000, 36V, 250W, 70Nm
Battery
DARFON, 36V, 504 Wh, integrated
Charger
DARFON 2A Smart charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.31 mm | 1.31 mm | 1.29 mm |
| Bottom Bracket Height | 354 mm | 354 mm | 354 mm |
| Front Center | 764 mm | 775 mm | 792 mm |
| Rake | 43 mm | 43 mm | 42 mm |
| Trail | 120 mm | 120 mm | 121 mm |
| Stack | 596 mm | 605 mm | 615 mm |
| Reach | 456 mm | 463 mm | 476 mm |
| Top Tube Length | 622 mm | 632 mm | 647 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 431 mm | 490 mm | 533 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1193 mm | 1204 mm | 1221 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 160 cm | 180 cm | 189 cm |
| Rider Max Height | 170 cm | 191 cm | 200 cm |
About this model
eXF 9019 is a Superior E Exf model. Superior launched 16 e-bikes of this model so far. Take a sneak peek at all Superior E Exf e-bikes models from 2020, by clicking here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Trail e-bikes average price
If you want an acceptable Trail e-bike you should know that the average price is 3365$. However, this doesn’t mean that if you spend less money on a Trail e-bike, you couldn’t get a decent one. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Trail e-bikes average weight
The average weight for Trail e-bikes is 23.7 kg (52.25 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
slightly lighter than average, eXF 9019 has a weight of 22.9 kg (50.49 lbs). In short, the average Trail e-bike weight is 3.49% higher than this one.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
eXF 9019 components
Fork
Superior eXF 9019 2020 e-bike is equipped with the RockShox Recon Silver RL fork, and has 140mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The eXF 9019 has a rear shock with a travel of 130mm. The model RockShox Deluxe Select Plus is the one installed in this e-bike. Rear shocks improve riding comfort and give you greater control over all terrains. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
When leaving the production line, the eXF 9019 model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
Superior eXF 9019 e-bike has 3 sizes, in the range of 160 cm – 200 cm (5.25 ft – 6.56 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
The Superior model is also equipped with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
