Superior eXF 9039 B 2023
2023 E-bike
Estimate price |
7,683$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 160mm -
Travel Rear 160mm -
Fork RockShox Lyrik Select
-
Groupset SLX, Deore -
Suspension Full -
Motor Bosch 250W 85Nm mid-drive -
Battery BOSCH PowerTube, 750Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
170cm - 181cm
LG
179cm - 191cm
XL
189cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alu X6 Ultralite MTB Trail SUE03.1, Advanced e-MTB Geometry, Travel 160 mm, BOSCH CX Performance 5G ready, Integrated 750Wh battery , 3D alloy one pice link, Alloy swingarm, Boost 12x148 mm, Inner cable routing, Dropped seat post ready
Suspension Fork
RockShox Lyrik Select RC, Tapered, DebonAir, 15x110mm axle, 160mm travel
Rear Shock
RockShox Super Deluxe Select R, size 230x65mm
Drivetrain
Rear Derailleur
SHIMANO SLX RD-M7100, Shadow Plus Design
Shift Levers
SHIMANO DEORE SL-M6100-IR, RAPIDFIRE Plus, 12speed
Cassette
SHIMANO DEORE CS-M6100, 12-speed, 10-51T
Crank
ONE Race, Alloy
Bottom Bracket
Bosch, press-fit
Chain
SHIMANO DEORE CN-M6100
Wheels
Rims
DT Swiss H 1900 SPLINE®, CL, 15x110mm, Tubeless Ready
Tires
Schwalbe Nobby Nic Evo, SuperTrail, TL-Easy, 29x2.60", ADDIX SpeedGrip
Brakes
Brakes
SHIMANO M6120, 4 piston, hydraulic disc brake
Cockpit
Stem
ONE ICR, Alloy, 35mm, 0°
Handlebar
ONE Alloy, 12mm rise, 760mm, 35mm
Headset
ACROS AZX-1051S, ICR, ZS56/28.6 - ZS56/40, BlockLock 120°, Stainless Bearings
Seat
Saddle
Fizi:k Aidon X5, Alloy
Seatpost
ONE Sport Dropper Post, Alloy, 30.9mm
Motor & Battery
Motor
BOSCH Performance Line CX, 85Nm
Battery
BOSCH PowerTube, 750Wh
Charger
BOSCH 4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.34 mm | 1.29 mm | 1.24 mm |
| Bottom Bracket Height | 347 mm | 347 mm | 347 mm |
| Front Center | 806 mm | 826 mm | 846 mm |
| Rake | 44 mm | 44 mm | 44 mm |
| Trail | 134 mm | 134 mm | 134 mm |
| Stack | 628 mm | 628 mm | 628 mm |
| Reach | 468 mm | 488 mm | 508 mm |
| Top Tube Length | 613 mm | 633 mm | 653 mm |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° |
| Seat Tube Length | 420 mm | 440 mm | 490 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 120 mm | 120 mm | 120 mm |
| Chainstay Length | 449 mm | 449 mm | 449 mm |
| Wheelbase | 1254 mm | 1274 mm | 1294 mm |
| Bottom Bracket Drop | 27 mm | 27 mm | 27 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 170 cm | 179 cm | 189 cm |
| Rider Max Height | 181 cm | 191 cm | 200 cm |
About this model
eXF 9039 B completes the Superior E Exf model. 21 e-bikes variations carry this model name so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Superior eXF 8089 2023 is the cheapest e-bike model and costs 4743$. Superior eXF 9049 R 2023 is the most expensive one and costs 7094$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Enduro e-bikes
Our math shows that the average cost of a dependable Enduro e-bike is 4785$. However, you could also get a good Enduro e-bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
At the moment of the release date, Superior eXF 9039 B price was 7094$. If we compare this with the average Enduro e-bike cost we notice that the price is 48.25% higher.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
eXF 9039 B components
Fork
The fork installed on this bike is the RockShox Lyrik Select model. The travel on this model is 160mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
Superior eXF 9039 B e-bike has the RockShox Super Deluxe Select R model installed, and has a travel of 160mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
As for the wheels, Superior eXF 9039 B 2023, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Nothing is more important on a bike than its ability to brake properly. Superior eXF 9039 B is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
This e-bike is available in 3 sizes. They vary from 170 cm – 200 cm (5.58 ft – 6.56 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Every bike should have a dropper post, and this one does. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
