Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Fork SunTour XCR 34
-
Groupset Deore, Shimano -
Suspension Hardtail -
Motor Shimano 250W 60Nm mid-drive -
Battery DARFON, 36V, 504 Wh, integrated -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
170cm - 181cm
LG
179cm - 191cm
XL
189cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alu X6 Ultralite, Advanced eMTB Geometry, SHIMANO STEPS ready, Prepared to 630Wh integrated battery, SR dropout, Boost 12x148 mm, Inner Cable Routing, dropper seatpost ready
Suspension Fork
SR Suntour XCR34 Air, 1-1/8", QR Type, Lockout, 120mm travel
Drivetrain
Rear Derailleur
SHIMANO DEORE RD-M6000 Shadow Plus
Shift Levers
SHIMANO DEORE SL-M6000-R RapidFire Plus, 10-speed
Cassette
SHIMANO CS-HG500-10, 11-42T
Crank
SHIMANO FC-E6100, 34T
Bottom Bracket
STEPS, press-fit
Chain
KMC e10S
Wheels
Front Hub
SHIMANO ALIVIO HB-MT400, 32H, CENTER LOCK, 15x110mm Thru Axle
Rear Hub
SHIMANO FH-MT400-B, 32H, CENTER LOCK, 12x148mm THRU Type AXLE
Rims
Stars J26S, 32H
Spokes
Sapim Galvanized Black
Tires
Schwalbe Smart Sam KevlarGuard, 29x2.60"
Brakes
Brakes
TEKTRO HD-M735, hydraulic disc brake
Cockpit
Stem
ONE1 TDS-661 Alloy, 31.8mm, 0°
Handlebar
ONE1 Alloy, MTB AL-325BT, 6° upsweep, 9° backsweep, 25mm rise, 720mm, 31.8mm
Grips
ONE1 VLG-1661D2N, Lock-On
Seat
Saddle
Selle Royal Vivo HRN
Seatpost
ONE1 Race Alloy, SP 218, 30.9mm
Motor & Battery
Motor
SHIMANO STEPS E7000, 36V, 250W, 60Nm
Battery
DARFON, 36V, 504 Wh, integrated
Charger
DARFON 2A Smart charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.38 mm | 1.33 mm |
| Bottom Bracket Height | 320 mm | 320 mm | 320 mm |
| Front Center | 750 mm | 758 mm | 778 mm |
| Rake | 42 mm | 41 mm | 41 mm |
| Trail | 121 mm | 114 mm | 114 mm |
| Stack | 631 mm | 637 mm | 637 mm |
| Reach | 441 mm | 460 mm | 480 mm |
| Top Tube Length | 617 mm | 637 mm | 657 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 431 mm | 482 mm | 533 mm |
| Head Tube Angle | 66 ° | 67 ° | 67 ° |
| Head Tube Length | 120 mm | 120 mm | 120 mm |
| Chainstay Length | 442 mm | 442 mm | 442 mm |
| Wheelbase | 1187 mm | 1195 mm | 1215 mm |
| Bottom Bracket Drop | 54 mm | 54 mm | 54 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 170 cm | 179 cm | 189 cm |
| Rider Max Height | 181 cm | 191 cm | 200 cm |
Model Overview
eXP 8069 is part of the Superior E Exp model. There are 8 e-bikes that carry this model name. You can easily view all of the Superior E Exp e-bikes models from 2020, here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Trail e-bikes average price
If you want an acceptable Trail e-bike you should know that the average price is 3365$. However, you could also get a good Trail e-bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Trail e-bikes average weight
If we make a quick analysis of the average weight of a Trail e-bike, we get 23.7 kg (52.25 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
With a weight of 22.2 kg (48.94 lbs), Superior e-bike is a bit lighter than average. In short, the average Trail e-bike weight is 6.76% higher than this one.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
eXP 8069 components
Fork
The fork installed on this bike is the SunTour XCR 34 model. The travel on this model is 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
When it comes to wheels, the eXP 8069 e-bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
Superior eXP 8069 e-bike has 3 sizes, in the range of 170 cm – 200 cm (5.58 ft – 6.56 ft). In conclusion, finding one for you shouldn’t be a problem.
