Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Fork SunTour XCR 34
-
Groupset Deore, Shimano -
Suspension Hardtail -
Motor Shimano 250W 60Nm mid-drive -
Battery DARFON, 36V, 504 Wh, integrated -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
170cm - 181cm
LG
179cm - 191cm
XL
189cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alu X6 Ultralite, Advanced eMTB Geometry, SHIMANO STEPS ready, Prepared to 630Wh integrated battery, SR dropout, Boost 12x148 mm, Inner Cable Routing, dropper seatpost ready
Suspension Fork
SR Suntour XCR34 Air, 1-1/8", QR Type, Lockout, 120mm travel
Drivetrain
Rear Derailleur
SHIMANO DEORE RD-M6000 Shadow Plus
Shift Levers
SHIMANO DEORE SL-M6000-R RapidFire Plus, 10-speed
Cassette
SHIMANO CS-HG500-10, 11-42T
Crank
SHIMANO FC-E6100, 34T
Bottom Bracket
STEPS, press-fit
Chain
KMC e10S
Wheels
Front Hub
SHIMANO ALIVIO HB-MT400, 32H, CENTER LOCK, 15x110mm Thru Axle
Rear Hub
SHIMANO FH-MT400-B, 32H, CENTER LOCK, 12x148mm THRU Type AXLE
Rims
Stars J26S, 32H
Spokes
Sapim Galvanized Black
Tires
Schwalbe Smart Sam KevlarGuard, 29x2.60"
Brakes
Brakes
TEKTRO HD-M735, hydraulic disc brake
Cockpit
Stem
ONE1 TDS-661 Alloy, 31.8mm, 0°
Handlebar
ONE1 Alloy, MTB AL-325BT, 6° upsweep, 9° backsweep, 25mm rise, 720mm, 31.8mm
Grips
ONE1 VLG-1661D2N, Lock-On
Seat
Saddle
Selle Royal Vivo HRN
Seatpost
ONE1 Race Alloy, SP 218, 30.9mm
Motor & Battery
Motor
SHIMANO STEPS E7000, 36V, 250W, 60Nm
Battery
DARFON, 36V, 504 Wh, integrated
Remote
SHIMANO SC-E7000, Clamp band
Charger
DARFON 2A Smart charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.38 mm | 1.33 mm |
| Bottom Bracket Height | 320 mm | 320 mm | 320 mm |
| Front Center | 750 mm | 758 mm | 778 mm |
| Rake | 42 mm | 41 mm | 41 mm |
| Trail | 121 mm | 114 mm | 114 mm |
| Stack | 631 mm | 637 mm | 637 mm |
| Reach | 441 mm | 460 mm | 480 mm |
| Top Tube Length | 617 mm | 637 mm | 657 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 431 mm | 482 mm | 533 mm |
| Head Tube Angle | 66 ° | 67 ° | 67 ° |
| Head Tube Length | 120 mm | 120 mm | 120 mm |
| Chainstay Length | 442 mm | 442 mm | 442 mm |
| Wheelbase | 1187 mm | 1195 mm | 1215 mm |
| Bottom Bracket Drop | 54 mm | 54 mm | 54 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 170 cm | 179 cm | 189 cm |
| Rider Max Height | 181 cm | 191 cm | 200 cm |
Model Overview
eXP 8069 completes the Superior E Exp model. Superior launched 8 e-bikes of this model so far. You can get a glimpse at all models from 2021, by clicking on this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Trail e-bikes average price
Our math shows that the average cost of a dependable Trail e-bike is 3365$. However, you could also get a good Trail e-bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Average weight for Trail e-bikes
The average weight for Trail e-bikes is 23.7 kg (52.25 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
With a weight of 22.2 kg (48.94 lbs), Superior e-bike is a bit lighter than average. To sum up, it’s 6.76% lighter than the average weight of Trail e-bikes.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
eXP 8069 components
Fork
The fork installed on this bike is the SunTour XCR 34 model. The travel on this model is 120mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
When it comes to wheels, the eXP 8069 e-bike is equipped with the 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
Nothing is more important on a bike than its ability to brake properly. Superior eXP 8069 is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
Superior eXP 8069 e-bike has 3 sizes, in the range of 170 cm – 200 cm (5.58 ft – 6.56 ft). In short, it won’t be difficult to find the right one for you.
