Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Fork RockShox Judy Silver TK
-
Groupset SLX, Shimano -
Suspension Hardtail -
Motor Shimano 250W 60Nm mid-drive -
Battery DARFON, 36V, 504 Wh, integrated -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
170cm - 181cm
LG
179cm - 191cm
XL
189cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alu X6 Ultralite, Advanced eMTB Geometry, SHIMANO STEPS ready, Prepared to 630Wh integrated battery, SR dropout, Boost 12x148 mm, Inner Cable Routing, dropper seatpost ready
Suspension Fork
RockShox Judy Silver TK, Tapered, 15x110mm axle, 120mm travel
Drivetrain
Rear Derailleur
SHIMANO SLX RD-M7000 Shadow Plus
Shift Levers
SHIMANO SLX SL-M7000-IR RapidFire Plus, 11-speed
Cassette
SunRace CS-MS8-11, 11-46T
Crank
SHIMANO FC-E8000, 34T
Bottom Bracket
STEPS, press-fit
Chain
KMC e11T
Wheels
Front Hub
SHIMANO ALIVIO HB-MT400, 32H, CENTER LOCK, 15x110mm Thru Axle
Rear Hub
SHIMANO FH-MT400-B, 32H, CENTER LOCK, 12x148mm THRU Type AXLE
Rims
Stars J26S, 32H
Spokes
Sapim Leader, Stainless Black
Tires
Schwalbe Smart Sam Performance, 29x2.60", ADDIX
Brakes
Brakes
TEKTRO HD-M745, hydraulic disc brake
Cockpit
Stem
ONE1 TDS-661 Alloy, 31.8mm, 0°
Handlebar
ONE1 Alloy, MTB AL-320BT, 3° upsweep, 9° backsweep, 20mm rise, 760mm, 31.8mm
Grips
ESI Chunky silicone grips
Seat
Saddle
fizik Taiga
Seatpost
ONE1 Race Alloy, SP 218, 30.9mm
Motor & Battery
Motor
SHIMANO STEPS E7000, 36V, 250W, 60Nm
Battery
DARFON, 36V, 504 Wh, integrated
Charger
DARFON 2A Smart charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.38 mm | 1.33 mm |
| Bottom Bracket Height | 320 mm | 320 mm | 320 mm |
| Front Center | 750 mm | 758 mm | 778 mm |
| Rake | 42 mm | 41 mm | 41 mm |
| Trail | 121 mm | 114 mm | 114 mm |
| Stack | 631 mm | 637 mm | 637 mm |
| Reach | 441 mm | 460 mm | 480 mm |
| Top Tube Length | 617 mm | 637 mm | 657 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 431 mm | 482 mm | 533 mm |
| Head Tube Angle | 66 ° | 67 ° | 67 ° |
| Head Tube Length | 120 mm | 120 mm | 120 mm |
| Chainstay Length | 442 mm | 442 mm | 442 mm |
| Wheelbase | 1187 mm | 1195 mm | 1215 mm |
| Bottom Bracket Drop | 54 mm | 54 mm | 54 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 170 cm | 179 cm | 189 cm |
| Rider Max Height | 181 cm | 191 cm | 200 cm |
About this model
eXP 9009 completes the Superior E Exp model. Superior released 8 e-bikes variations of this model so far. Check out the entire range from 2020 of this model, by clicking this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Trail e-bikes
According to our math, the average price for a trustworthy Trail e-bike is 3365$. However, even though the average price of a Trail e-bike is lower, you might still be able to get a top-quality e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Average weight for Trail e-bikes
Trail e-bikes weigh an average of 23.7 kg (52.25 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
a bit lighter than average, eXP 9009 has a weight of 21.8 kg (48.06 lbs). In other words, this model is 8.72% lighter than the average Trail e-bike.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork
The eXP 9009 comes factory-installed with the RockShox Judy Silver TK fork. This has a travel range of 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
When it comes to wheels, the eXP 9009 e-bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
Nothing is more important on a bike than its ability to brake properly. Superior eXP 9009 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
Superior eXP 9009 e-bike has 3 sizes, in the range of 170 cm – 200 cm (5.58 ft – 6.56 ft). In conclusion, finding one for you shouldn’t be a problem.
