Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Fork RockShox Paragon Gold RL -
Groupset Deore, Shimano -
Suspension Hardtail -
Motor Shimano 250W 60Nm mid-drive -
Battery DARFON, 36V, 504 Wh, integrated -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
160cm - 170cm
LG
180cm - 191cm
XL
189cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alu X6 Ultralite, Sport eMTB Geometry, Smooth Welding, SHIMANO STEPS ready, NEW integrated battery, SR dropout, Boost 12x148 mm, Inner Cable Routing, dropper seatpost ready
Suspension Fork
RockShox Paragon Gold RL, Tapered, SoloAir, 65mm travel
Drivetrain
Rear Derailleur
SHIMANO DEORE RD-M6100 Shadow Plus
Shift Levers
SHIMANO DEORE SL-M6100-R RapidFire Plus, 12-speed
Cassette
SHIMANO CS-M6100-12, 10-51T
Crank
SHIMANO FC-E6100, 34T
Bottom Bracket
STEPS, press-fit
Chain
CHAIN SHIMANO CN-M6100
Pedals
VP Components VP-836
Wheels
Front Hub
SHIMANO HB-M4050, 32H, CENTER LOCK, QR Type
Rear Hub
SHIMANO FH-MT410, 32H, CENTER LOCK, 12x148mm THRU Type AXLE
Rims
Stars J26S, 32H
Spokes
Sapim Leader, Stainless Black
Tires
Schwalbe G-One Bite, 28x2.00", reflective tape
Brakes
Brakes
TEKTRO HD-EU815, hydraulic disc brake
Cockpit
Stem
ONE1 TDS-661 Alloy, 31.8mm, 0°
Handlebar
ONE1 Alloy, MTB AL-725, 3° upsweep, 7° backsweep, 20mm rise, 720mm, 31.8mm
Grips
Velo VLG-1777D2
Seat
Saddle
Selle Royal LIFT
Seatpost
ONE1 Sport Alloy, SP C207, 30.9mm
Motor & Battery
Motor
SHIMANO STEPS E7000, 36V, 250W, 60Nm
Battery
DARFON, 36V, 504 Wh, integrated
Remote
SHIMANO SC-E5000, Clamp band
Charger
DARFON 2A Smart Plus charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.4 mm | 1.34 mm |
| Bottom Bracket Height | 276 mm | 276 mm | 276 mm |
| Front Center | 683 mm | 703 mm | 723 mm |
| Rake | 46 mm | 46 mm | 46 mm |
| Trail | 86 mm | 86 mm | 86 mm |
| Stack | 601 mm | 601 mm | 601 mm |
| Reach | 408 mm | 428 mm | 448 mm |
| Top Tube Length | 587 mm | 607 mm | 627 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 431 mm | 482 mm | 533 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 120 mm | 120 mm | 120 mm |
| Chainstay Length | 447 mm | 447 mm | 447 mm |
| Wheelbase | 1123 mm | 1143 mm | 1163 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 160 cm | 180 cm | 189 cm |
| Rider Max Height | 170 cm | 191 cm | 200 cm |
About this model
eXR 6090 Touring belongs to the Superior E Exr model. Superior launched 28 e-bikes of this model so far. You can easily view all of the Superior E Exr e-bikes models from 2021, here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Touring e-bikes
According to our math, the average price for a trustworthy Touring e-bike is 2429$. However, even though the average price of a Touring e-bike is lower, you might still be able to get a top-quality e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
Touring e-bikes average weight
Touring e-bikes weigh an average of 25.55 kg (56.33 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
With a weight of 22.9 kg (50.49 lbs), Superior e-bike is considerably lighter than average. In short, the average Touring e-bike weight is 11.57% higher than this one.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork
Superior eXR 6090 Touring 2021 e-bike is equipped with the RockShox Paragon Gold RL fork, and has mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
As for the wheels, Superior eXR 6090 Touring 2021, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The eXR 6090 Touring has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
eXR 6090 Touring comes in 3 sizes, that range from 160 cm – 200 cm (5.25 ft – 6.56 ft). In conclusion, you won’t have a problem finding one that suits you.
