Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork SunTour XCT
-
Groupset Acera, Altus -
Suspension Hardtail -
Drivetrain 1 × 8 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alu 6061 T6 Double Butted, Advanced Junior Geometry,1xOptimized, BB BSA, SR dropout
Suspension Fork
SR Suntour XCT30, 1-1/8", Coil, QR Type, 100mm travel
Drivetrain
Rear Derailleur
SHIMANO ACERA RD-M360-L
Shift Levers
SHIMANO ALTUS SL-M315-8R RapidFire Plus, 8-speed
Cassette
SHIMANO CS-HG31-8, 11-34T
Crank
Wheel Top SXB4BL-WM, 32T
Bottom Bracket
Thun Ibex 120mm, BSA, shell 68mm
Chain
KMC Z8.3
Pedals
Marwi SP-610
Wheels
Front Hub
SHIMANO HB-TX505, 32H, CENTER LOCK, QR Type
Rear Hub
SHIMANO FH-TX505-8, 32H, CENTER LOCK, M10x135mm, QR Type
Rims
Stars J20S, 32H
Spokes
Sapim Galvanized Black
Tires
Schwalbe Smart Sam KevlarGuard, 27.5x2.10"
Brakes
Brakes
SHIMANO BL-MT200/BR-MT200, hydraulic disc brake
Cockpit
Stem
ONE1 MAS-MD60368 Alloy, 25.4mm, 15°
Handlebar
ONE1 Alloy, MTB AL-718BT, 34mm rise, 600mm, 25.4mm
Grips
ONE1 VLG-1661D2N, Lock-On
Seat
Saddle
Selle Royal Junior
Seatpost
ONE1 Sport Alloy, SP C208, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM |
|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.34 mm |
| Front Center | 632 mm | 671 mm |
| Rake | 44 mm | 42 mm |
| Stack | 560 mm | 560 mm |
| Reach | 376 mm | 417 mm |
| Top Tube Length | 541 mm | 580 mm |
| Seat Tube Angle | 74 ° | 74 ° |
| Seat Tube Length | 343 mm | 393 mm |
| Head Tube Angle | 69 ° | 69 ° |
| Head Tube Length | 90 mm | 90 mm |
| Chainstay Length | 429 mm | 429 mm |
| Wheelbase | 1058 mm | 1097 mm |
| Bottom Bracket Drop | 40 mm | 40 mm |
| Wheels | 27" | 27" |
Model Overview
Racer XC 27 DB is part of the Superior Racer model. There are 6 bikes that carry this model name. You can easily view all of the Superior Racer bikes models from 2021, here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Mountain bikes
If you want to purchase a solid Mountain bike, it is important to know that the average cost is 616$. However, even though the average price of a Mountain bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Average weight for Mountain bikes
Mountain bikes weigh an average of 11.4 kg (25.13 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Weighing 12.7 kg (28 lbs), the Racer XC 27 DB model is considerably heavier than average. In short, the average Mountain bike weight is 11.4% lower than this one.
Overview of components
Fork
The fork installed on this bike is the SunTour XCT model. The travel on this model is 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
When leaving the production line, the Racer XC 27 DB model has 27.5″ aluminum wheels. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Superior Racer XC 27 DB has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
