Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 60mm -
Fork Zoom
-
Groupset Altus, Tourney -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Rim
Sizing
Recommended size guide.
MD
165cm - 176cm
LG
170cm - 181cm
XL
179cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alu 6061 T6 Double Butted, Advanced Touring Geometry, Integrated Cable Routing, BB BSA
Suspension Fork
ZOOM 187 AMS, 1-1/8", Coil, QR Type, 60mm travel
Drivetrain
Rear Derailleur
SHIMANO ALTUS RD-M310-L
Front Derailleur
SHIMANO TY FD-TY510-TS3, Top Swing, Dual Pull
Shift Levers
SHIMANO ALTUS ST-EF500-L, EZ FIRE Plus, 3-speed
Cassette
SHIMANO MF-TZ500, 7-speed, 14-28T, Freewheel
Crank
SHIMANO FC-TY501, 48-38-28T
Bottom Bracket
SHIMANO BB-UN101, 122.5mm, BSA, shell 73mm
Chain
KMC Z8
Pedals
Marwi SP-872N
Wheels
Front Hub
ONE, 36H, CL, 3/8"26Tx100x14, Nut Type
Rear Hub
ONE, 36H, Freewheel, 3/8"x26Tx135, NUT Type
Rims
STARS J19SZ, 36H
Spokes
SAPIM Leader, Stainless Black
Tires
WTB Riddler Comp, 29x1.75", Reflective tape
Brakes
Brakes
Saccon, V-Brake
Cockpit
Stem
ONE Race, Alloy, 31,8mm, ±15°
Handlebar
ONE Alloy, 12mm rise, 660mm, 31.8mm
Headset
FSA NO.10P, Semi-Cartrige, 1-1/8
Seat
Saddle
Selle Royal Rio Plus
Seatpost
ONE, Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.44 mm | 1.43 mm |
| Front Center | 665 mm | 678 mm | 682 mm |
| Rake | 54 mm | 54 mm | 65 mm |
| Trail | 70 mm | 70 mm | 51 mm |
| Stack | 606 mm | 612 mm | 615 mm |
| Reach | 416 mm | 426 mm | 429 mm |
| Top Tube Length | 596 mm | 606 mm | 616 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 440 mm | 483 mm | 533 mm |
| Head Tube Angle | 70 ° | 70 ° | 71 ° |
| Head Tube Length | 160 mm | 160 mm | 160 mm |
| Chainstay Length | 451 mm | 451 mm | 451 mm |
| Wheelbase | 1108 mm | 1121 mm | 1125 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 165 cm | 170 cm | 179 cm |
| Rider Max Height | 176 cm | 181 cm | 190 cm |
About this model
RX 510 is part of the Superior Rx model. Superior released 5 bikes variations of this model so far. You can get a glimpse at all models from 2023, by clicking on this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Hybrid bikes
If you want an acceptable Hybrid bike you should know that the average price is 562$. However, you could also get a good Hybrid bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork
The RX 510 comes factory-installed with the Zoom fork. This has a travel range of 60mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
When leaving the production line, the RX 510 model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Superior RX 510 has Rim brakes installed. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they are not nearly as effective as hydraulic brakes are.
Sizes
Superior RX 510 bike has 3 sizes, in the range of 165 cm – 190 cm (5.41 ft – 6.23 ft). In conclusion, it won’t take much to find one that’s right for you.
