Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 60mm -
Fork Zoom
-
Groupset Altus, Tourney -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Rim
Sizing
Recommended size guide.
MD
160cm - 171cm
LG
169cm - 180cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alu 6061 T6 Double Butted, Advanced Touring Geometry, Integrated Cable Routing, BB BSA
Suspension Fork
ZOOM 187 AMS, 1-1/8", Coil, QR Type, 60mm travel
Drivetrain
Rear Derailleur
SHIMANO ALTUS RD-M310-L
Front Derailleur
SHIMANO TY FD-TY510-TS3, Top Swing, Dual Pull
Shift Levers
SHIMANO ALTUS ST-EF500-L, EZ FIRE Plus, 3-speed
Cassette
SHIMANO MF-TZ500, 7-speed, 14-28T, Freewheel
Crank
SHIMANO FC-TY501, 48-38-28T
Bottom Bracket
SHIMANO BB-UN101, 122.5mm, BSA, shell 73mm
Chain
KMC Z8
Pedals
Marwi SP-872N
Wheels
Front Hub
ONE, 36H, CL, 3/8"26Tx100x14, Nut Type
Rear Hub
ONE, 36H, Freewheel, 3/8"x26Tx135, NUT Type
Rims
STARS J19SZ, 36H
Spokes
SAPIM Leader, Stainless Black
Tires
WTB Riddler Comp, 29x1.75", Reflective tape
Brakes
Brakes
Saccon, V-Brake
Cockpit
Stem
ONE Race, Alloy, 31,8mm, ±15°
Handlebar
ONE Alloy, 12mm rise, 660mm, 31.8mm
Headset
FSA NO.10P, Semi-Cartrige, 1-1/8
Seat
Saddle
Selle Royal Rio
Seatpost
ONE, Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Stack Reach Ratio | 1.55 mm | 1.5 mm |
| Front Center | 665 mm | 680 mm |
| Rake | 55 mm | 55 mm |
| Trail | 68 mm | 68 mm |
| Stack | 630 mm | 630 mm |
| Reach | 406 mm | 421 mm |
| Top Tube Length | 586 mm | 601 mm |
| Seat Tube Angle | 74 ° | 74 ° |
| Seat Tube Length | 440 mm | 483 mm |
| Head Tube Angle | 70 ° | 70 ° |
| Head Tube Length | 180 mm | 180 mm |
| Chainstay Length | 451 mm | 451 mm |
| Wheelbase | 1108 mm | 1123 mm |
| Bottom Bracket Drop | 65 mm | 65 mm |
| Wheels | 700 | 700 |
| Rider Min Height | 160 cm | 169 cm |
| Rider Max Height | 171 cm | 180 cm |
Model Overview
RX 510 L is a Superior Rx model. 5 bikes variations carry this model name so far. Check out the entire range from 2023 of this model, by clicking this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Hybrid bikes average price
Our math shows that the average cost of a dependable Hybrid bike is 562$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Hybrid bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork
The RX 510 L comes factory-installed with the Zoom fork. This has a travel range of 60mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
The wheels on RX 510 L are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The RX 510 L has Rim brakes. Rim brakes deliver an average performance overall. However, they have problems in wet conditions.
Sizes
RX 510 L comes in 2 sizes, that range from 160 cm – 180 cm (5.25 ft – 5.91 ft). In short, you can easily find one that suits you.
