Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 60mm -
Fork Zoom
-
Groupset Acera, Tourney -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 176cm
LG
170cm - 181cm
XL
179cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alu 6061 T6 Double Butted, Advanced Touring Geometry, Integrated Cable Routing, BB BSA
Suspension Fork
ZOOM 187D AMS, 1-1/8", Coil, QR Type, 60mm travel
Drivetrain
Rear Derailleur
SHIMANO ACERA RD-M3020
Front Derailleur
SHIMANO TOURNEY TX FD-TX800-TS3, Top Swing, Dual Pull
Shift Levers
SHIMANO ST-EF505, 3-speed
Cassette
SHIMANO CS-HG31, 8-speed, 11-34T
Crank
SHIMANO FC-TY501, 48-38-28T
Bottom Bracket
SHIMANO BB-UN101, 122.5mm, BSA, shell 73mm
Chain
KMC Z8
Pedals
Marwi SP-872N
Wheels
Front Hub
ONE, 32H, CL, M9X100mm, QR Type
Rear Hub
SHIMANO FH-TX505-8, 36H, CL, M10x135mm, QR Type
Rims
STARS J19DC, Disc, 32H
Spokes
SAPIM Leader, Stainless Black
Tires
WTB Riddler Comp, 29x1.75", Reflective tape
Brakes
Brakes
SHIMANO MT200, hydraulic disc brake
Cockpit
Stem
ONE Race, Alloy, 31,8mm, ±15°
Handlebar
ONE Alloy, 12mm rise, 660mm, 31.8mm
Headset
FSA NO.10P, Semi-Cartrige, 1-1/8
Seat
Saddle
Selle Royal Rio Plus
Seatpost
ONE, Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.44 mm | 1.43 mm |
| Front Center | 665 mm | 678 mm | 682 mm |
| Rake | 54 mm | 54 mm | 65 mm |
| Trail | 70 mm | 70 mm | 51 mm |
| Stack | 606 mm | 612 mm | 615 mm |
| Reach | 416 mm | 426 mm | 429 mm |
| Top Tube Length | 596 mm | 606 mm | 616 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 440 mm | 483 mm | 533 mm |
| Head Tube Angle | 70 ° | 70 ° | 71 ° |
| Head Tube Length | 160 mm | 160 mm | 160 mm |
| Chainstay Length | 451 mm | 451 mm | 451 mm |
| Wheelbase | 1108 mm | 1121 mm | 1125 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 165 cm | 170 cm | 179 cm |
| Rider Max Height | 176 cm | 181 cm | 190 cm |
Model Overview
RX 530 belongs to the Superior Rx model. There are 5 bikes that carry this model name. Check out the entire range from 2023 of this model, by clicking this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Hybrid bikes average price
According to our math, the average price for a trustworthy Hybrid bike is 562$. However, even if your budget is less than the average, you might still be able to get a top-quality Hybrid bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
RX 530 components
Fork
Superior RX 530 2023 bike is equipped with the Zoom fork, and has 60mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
As for the wheels, Superior RX 530 2023, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Superior RX 530 has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 165 cm – 190 cm (5.41 ft – 6.23 ft). In conclusion, finding one for you shouldn’t be a problem.
