Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Travel Front 60mm -
Fork Zoom
-
Groupset Nexus -
Suspension Hardtail -
Motor Bosch 250W 50Nm mid-drive -
Battery BOSCH PowerPack, 500Wh -
Drivetrain Internally Geared Hub -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
150cm - 161cm
MD
159cm - 171cm
LG
169cm - 180cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alloy 6061 T6, e-Comfort Geometry, Bosch
Suspension Fork
ZOOM 187D AMS, 1-1/8", Coil, QR Type, 60mm travel
Drivetrain
Shift Levers
SHIMANO NEXUS SL-C3000-7, REVOSHIFT, 7-speed
Cassette
SHIMANO NEXUS, Sprocket, 18T
Crank
ONE, Alloy
Bottom Bracket
Bosch, press-fit
Chain
KMC Z1 EPT
Pedals
Marwi SP-823
Wheels
Front Hub
ONE, 36H, CL, M9x100mm, QR Type
Rear Hub
SHIMANO NEXUS SG-C3001-7D, 36H, CL, 135x187mm
Rims
STARS J19ZK, Disc, 36H
Spokes
SAPIM Leader, Stainless Black
Tires
CST OTIS, 47-622, Reflective Tape
Brakes
Brakes
SHIMANO MT200, hydraulic disc brake
Cockpit
Stem
ONE, Alloy, 31.8mm, Adjustable
Handlebar
ONE Alloy, 38mm rise, 620mm, 31.8mm
Headset
FSA TH-805ST, Semi-Cartrige, 1-1/8
Seat
Saddle
Selle Royal Giara
Seatpost
ONE, Alloy, 30.0mm
Motor & Battery
Motor
BOSCH Active Line Plus, 50Nm
Battery
BOSCH PowerPack, 500Wh
Charger
BOSCH 2A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.54 mm | 1.57 mm | 1.6 mm |
| Front Center | 649 mm | 655 mm | 661 mm |
| Rake | 45 mm | 45 mm | 45 mm |
| Trail | 86 mm | 80 mm | 76 mm |
| Stack | 610 mm | 632 mm | 654 mm |
| Reach | 396 mm | 403 mm | 409 mm |
| Top Tube Length | 586 mm | 606 mm | 626 mm |
| Seat Tube Angle | 72.5 ° | 72 ° | 71.5 ° |
| Seat Tube Length | 440 mm | 500 mm | 540 mm |
| Head Tube Angle | 69 ° | 69.8 ° | 70.5 ° |
| Head Tube Length | 170 mm | 180 mm | 190 mm |
| Chainstay Length | 491 mm | 491 mm | 491 mm |
| Wheelbase | 1133 mm | 1139 mm | 1145 mm |
| Bottom Bracket Drop | 62 mm | 62 mm | 62 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 150 cm | 159 cm | 169 cm |
| Rider Max Height | 161 cm | 171 cm | 180 cm |
Model Overview
SBC 200 is part of the Superior E Sbc model. Superior launched 3 e-bikes of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Superior SBC 400i L 2023 is the most economical model, with a starting price of 3176$. Superior SBC 450i L 2023 on the other hand costs 3652$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for General Urban e-bikes
If you want to purchase a solid General Urban e-bike, it is important to know that the average cost is 2098$. However, this doesn’t mean that if you spend less money on a General Urban e-bike, you couldn’t get a decent one. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Overview of components
Fork
The Zoom is included from the factory. It has a travel distance of 60mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
When leaving the production line, the SBC 200 model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The SBC 200 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 150 cm – 180 cm (4.92 ft – 5.91 ft). In conclusion, finding one for you shouldn’t be a problem.
