Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Fork Zoom -
Groupset microSHIFT -
Suspension Hardtail -
Motor Bosch 250W 50Nm mid-drive -
Battery BOSCH PowerPack, 500Wh -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
150cm - 161cm
MD
159cm - 171cm
LG
169cm - 180cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alloy 6061 T6, e-Comfort Geometry, Bosch
Suspension Fork
ZOOM 187D AMS, 1-1/8", Coil, QR Type, 60mm travel
Drivetrain
Rear Derailleur
microSHIFT XLE10 RDM61S
Shift Levers
microSHIFT XLE10 SLM760R, Xpress Shifter, 10-speed
Cassette
microSHIFT CSH100, 10 speed, 11-34T
Crank
ONE, Alloy
Bottom Bracket
Bosch, press-fit
Chain
KMC e10S
Pedals
Marwi SP-823
Wheels
Front Hub
ONE, 36H, CL, M9x100mm, QR Type
Rear Hub
ONE, 36H, CL, M10x135, QR Type
Rims
STARS J19DC, Disc, 36H
Spokes
SAPIM Leader, Stainless Black
Tires
CST OTIS, 47-622, Reflective Tape
Brakes
Brakes
SHIMANO MT200, hydraulic disc brake
Cockpit
Stem
ONE, Alloy, 31.8mm, Adjustable
Handlebar
ONE Alloy, 38mm rise, 620mm, 31.8mm
Headset
FSA TH-805ST, Semi-Cartrige, 1-1/8
Seat
Saddle
Selle Royal Nuvola
Seatpost
ONE, Alloy, 30.0mm
Motor & Battery
Motor
BOSCH Active Line Plus, 50Nm
Battery
BOSCH PowerPack, 500Wh
Charger
BOSCH 2A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.54 mm | 1.57 mm | 1.6 mm |
| Bottom Bracket Height | 274 mm | 274 mm | 274 mm |
| Front Center | 649 mm | 655 mm | 661 mm |
| Rake | 45 mm | 45 mm | 45 mm |
| Trail | 81 mm | 76 mm | 71 mm |
| Stack | 610 mm | 632 mm | 654 mm |
| Reach | 396 mm | 403 mm | 409 mm |
| Top Tube Length | 586 mm | 606 mm | 626 mm |
| Seat Tube Angle | 72.5 ° | 72 ° | 71.5 ° |
| Seat Tube Length | 440 mm | 500 mm | 540 mm |
| Head Tube Angle | 69 ° | 69.8 ° | 70.5 ° |
| Head Tube Length | 170 mm | 180 mm | 190 mm |
| Chainstay Length | 491 mm | 491 mm | 491 mm |
| Wheelbase | 1133 mm | 1139 mm | 1145 mm |
| Bottom Bracket Drop | 62 mm | 62 mm | 62 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 150 cm | 159 cm | 169 cm |
| Rider Max Height | 161 cm | 171 cm | 180 cm |
About this model
SBT 300 L belongs to the Superior E Sbt model. Superior released 2 e-bikes variations of this model so far. You can easily view all of the Superior E Sbt e-bikes models from 2023, here.
Model range prices
Superior SBT 300 L 2023 is the cheapest e-bike model and costs 2964$. Superior SBT 600i L 2023 is the most expensive one and costs 3176$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Touring e-bikes
If you want an acceptable Touring e-bike you should know that the average price is 2429$. However, even though the average price of a Touring e-bike is lower, you might still be able to get a top-quality e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 2964$. If we compare this with the average Touring e-bike cost we notice that the price is 22.03% higher.
Overview of components
Fork
The fork installed on this bike is the Zoom model. The travel on this model is mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Fork material
When it comes to the fork, this e-bike has a carbon one, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The SBT 300 L 2023 e-bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The SBT 300 L has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
This e-bike is available in 3 sizes. They vary from 150 cm – 180 cm (4.92 ft – 5.91 ft). In conclusion, you won’t have a problem finding one that suits you.
