Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 60mm -
Fork Zoom
-
Groupset Alivio, Acera -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
LG
170cm - 181cm
XL
179cm - 191cm
XXL
189cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alu 6061 T6 Double Butted, Advanced Touring Geometry, Integrated Cable Routing, BB BSA
Suspension Fork
ZOOM 187D AMS, 1-1/8", Coil, QR Type, 60mm travel
Drivetrain
Rear Derailleur
SHIMANO ALIVIO RD-M3100, Shadow Design
Front Derailleur
SHIMANO ACERA FD-T3000, Top Swing, DUAL Pull
Shift Levers
SHIMANO ALIVIO SL-M3100, RAPIDFIRE Plus, 3-speed
Cassette
SHIMANO CS-HG200, 9-speed, 11-34T
Crank
SHIMANO FC-M371, 48-36-26T
Bottom Bracket
SHIMANO BB-UN101, 122.5mm, BSA, shell 73mm
Chain
KMC X9
Pedals
Marwi SP-823
Wheels
Front Hub
SHIMANO DH-3D37-QR, 36H, CL, M9X100mm, QR Type
Rear Hub
SHIMANO FH-TX505-8, 36H, CL, M10x135mm, QR Type
Rims
STARS J19DC, Disc, 36H
Spokes
SAPIM Leader, Stainless Black
Tires
Schwalbe Road Cruiser, KevlarGuard, 40-622, Reflective tape
Brakes
Brakes
SHIMANO MT200, hydraulic disc brake
Cockpit
Stem
ONE, Alloy, 25.4mm, Adjustable
Handlebar
ONE Alloy, 620mm, 25.4mm
Headset
FSA TH-807ST, Semi-Cartrige, 1-1/8
Seat
Saddle
Selle Royal Rio Plus
Seatpost
ONE, Alloy, Suspension, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | LG | XL | XXL |
|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.44 mm | 1.44 mm |
| Front Center | 678 mm | 682 mm | 687 mm |
| Rake | 54 mm | 65 mm | 55 mm |
| Trail | 70 mm | 51 mm | 59 mm |
| Stack | 604 mm | 607 mm | 628 mm |
| Reach | 418 mm | 421 mm | 435 mm |
| Top Tube Length | 598 mm | 608 mm | 628 mm |
| Seat Tube Angle | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 483 mm | 533 mm | 584 mm |
| Head Tube Angle | 70 ° | 71 ° | 71.5 ° |
| Head Tube Length | 160 mm | 160 mm | 180 mm |
| Chainstay Length | 443 mm | 443 mm | 443 mm |
| Wheelbase | 1113 mm | 1117 mm | 1122 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 170 cm | 179 cm | 189 cm |
| Rider Max Height | 181 cm | 191 cm | 200 cm |
Model Overview
STK 500 completes the Superior Stk model. Superior released 8 bikes variations of this model so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Superior STK 100 L 2023 is the cheapest bike model and costs 687$. Superior STK 700 L 2023 is the most expensive one and costs 1217$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Hybrid bikes average price
According to our math, the average price for a trustworthy Hybrid bike is 562$. However, this doesn’t mean that if you spend less money on a Hybrid bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2023 for 952$. If we compare this with the average Hybrid bike cost we notice that the price is 69.4% more expensive.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
STK 500 components
Fork
This bike has the Zoom fork installed. The fork’s travel is 60mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
When it comes to wheels, the STK 500 bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Superior STK 500 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
Superior STK 500 bike has 3 sizes, in the range of 170 cm – 200 cm (5.58 ft – 6.56 ft). In conclusion, you won’t have a problem finding one that suits you.
