Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 60mm -
Fork Zoom
-
Groupset Alivio, Acera -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
160cm - 171cm
LG
169cm - 181cm
XL
179cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alu 6061 T6 Double Butted, Advanced Touring Geometry, Integrated Cable Routing, BB BSA
Suspension Fork
ZOOM 187D AMS, 1-1/8", Coil, QR Type, 60mm travel
Drivetrain
Rear Derailleur
SHIMANO ALIVIO RD-M3100, Shadow Design
Front Derailleur
SHIMANO ACERA FD-T3000, Top Swing, DUAL Pull
Shift Levers
SHIMANO ALIVIO SL-M3100, RAPIDFIRE Plus, 3-speed
Cassette
SHIMANO CS-HG200, 9-speed, 11-34T
Crank
SHIMANO FC-M371, 48-36-26T
Bottom Bracket
SHIMANO BB-UN101, 122.5mm, BSA, shell 73mm
Chain
KMC X9
Pedals
Marwi SP-823
Wheels
Front Hub
SHIMANO DH-3D37-QR, 36H, CL, M9X100mm, QR Type
Rear Hub
SHIMANO FH-TX505-8, 36H, CL, M10x135mm, QR Type
Rims
STARS J19DC, Disc, 36H
Spokes
SAPIM Leader, Stainless Black
Tires
Schwalbe Road Cruiser, KevlarGuard, 40-622, Reflective tape
Brakes
Brakes
SHIMANO MT200, hydraulic disc brake
Cockpit
Stem
ONE, Alloy, 25.4mm, Adjustable
Handlebar
ONE Alloy, 620mm, 25.4mm
Headset
FSA TH-807ST, Semi-Cartrige, 1-1/8
Seat
Saddle
Selle Royal Rio
Seatpost
ONE, Alloy, Suspension, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.55 mm | 1.5 mm | 1.46 mm |
| Front Center | 665 mm | 680 mm | 690 mm |
| Rake | 55 mm | 55 mm | 55 mm |
| Trail | 68 mm | 68 mm | 68 mm |
| Stack | 630 mm | 630 mm | 630 mm |
| Reach | 406 mm | 421 mm | 431 mm |
| Top Tube Length | 586 mm | 601 mm | 611 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 440 mm | 483 mm | 533 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 180 mm | 180 mm | 180 mm |
| Chainstay Length | 451 mm | 451 mm | 451 mm |
| Wheelbase | 1108 mm | 1123 mm | 1133 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 160 cm | 169 cm | 179 cm |
| Rider Max Height | 171 cm | 181 cm | 190 cm |
Model Overview
STK 500 L completes the Superior Stk model. 8 bikes variations carry this model name so far. Take a sneak peek at all Superior Stk bikes models from 2023, by clicking here.
Model range prices
Superior STK 100 L 2023 is the most economical model, with a starting price of 687$. Superior STK 700 L 2023 on the other hand costs 1217$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Hybrid bikes average price
Our math shows that the average cost of a dependable Hybrid bike is 562$. However, even if your budget is less than the average, you might still be able to get a top-quality Hybrid bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Superior released this model in 2023, its price was 952$. Doing a quick comparison, we notice that STK 500 L price is 69.4% higher than the average cost of a Hybrid bike.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
STK 500 L components
Fork
The Zoom is included from the factory. It has a travel distance of 60mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
The STK 500 L 2023 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 3 sizes. They vary from 160 cm – 190 cm (5.25 ft – 6.23 ft). In conclusion, it won’t take much to find one that’s right for you.
