Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra Di2 -
Suspension Rigid -
Drivetrain 2 × 11 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
165cm - 175cm
MD
170cm - 180cm
LG
175cm - 185cm
XL
180cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon X-Road Race Mid Modulus, Road Advanced Geometry, Disc Brake Flat Mount, BB865, SH dropout, Thru Axle 12x142 mm, Inner cable routing, Di2 compatible, mudguards ready
Suspension Fork
X-Road Team Issue 28", Carbon rigid, Ahead 1-1/8x1.5", 12x100mm axle
Drivetrain
Rear Derailleur
SHIMANO ULTEGRA RD-RX805 Shadow Plus
Front Derailleur
SHIMANO ULTEGRA Di2 FD-R8050, BRAZED-ON Type
Cassette
SHIMANO CS-HG800-11, 11-34T
Crank
SHIMANO ULTEGRA FC-R8000 Hollowtech II, 50-34T
Bottom Bracket
SHIMANO BB-71-41B PressFit, shell 41x86.5mm, BB accessories
Chain
KMC X11L
Wheels
Rims
DT Swiss ERC 1400 Spline 47, 12x100mm, CENTER LOCK, Tubeless, DT Swiss ERC 1400 Spline 47; 12x142mm, CENTER LOCK, Tubeless
Tires
Schwalbe Pro One Evo, 28x1.20", ADDIX
Brakes
Brakes
SHIMANO ST-R8070/BR-R8070, hydraulic disc brake
Cockpit
Stem
ONE1 TDS-660 Alloy, 31.8mm, 7°, 110mm
Handlebar
ONE1 Carbon, CRB-DR901ACF, 31.8mm
Grips
Velo VLF-8111
Seat
Saddle
fizik Antares Versus EVO R5
Seatpost
ONE1 Carbon, SP0225380AERO
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.48 mm | 1.48 mm | 1.47 mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm | 279 mm |
| Front Center | 588 mm | 594 mm | 608 mm | 630 mm |
| Rake | 45 mm | 46 mm | 45 mm | 44 mm |
| Trail | 73 mm | 68 mm | 66 mm | 67 mm |
| Stack | 530 mm | 551 mm | 572 mm | 591 mm |
| Reach | 370 mm | 373 mm | 386 mm | 402 mm |
| Top Tube Length | 525 mm | 538 mm | 562 mm | 584 mm |
| Seat Tube Angle | 73.8 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 462 mm | 482 mm | 502 mm | 522 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72 ° | 72 ° |
| Head Tube Length | 120 mm | 140 mm | 160 mm | 180 mm |
| Chainstay Length | 406 mm | 406 mm | 406 mm | 406 mm |
| Wheelbase | 984 mm | 990 mm | 1004 mm | 1026 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 165 cm | 170 cm | 175 cm | 180 cm |
| Rider Max Height | 175 cm | 180 cm | 185 cm | 200 cm |
Model Overview
X-ROAD Team Issue R is part of the Superior X Road model. 26 bikes variations carry this model name so far. You can get a glimpse at all models from 2021, by clicking on this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Gravel bikes
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Average weight for Gravel bikes
On a deeper look, we notice that the average weight of a Gravel bike is 8.13 kg (17.92 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
X-ROAD Team Issue R weighs 7.8 kg (17.2 lbs) and is slightly lighter than the average. In other words, this model is 4.23% lighter than the average Gravel bike.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
X-ROAD Team Issue R components
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The wheels on X-ROAD Team Issue R are the 700c carbon type. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Superior X-ROAD Team Issue R is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Superior X-ROAD Team Issue R bike has 4 sizes, in the range of 165 cm – 200 cm (5.41 ft – 6.56 ft). In conclusion, it won’t take much to find one that’s right for you.
