Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork SunTour XCM HLO
-
Groupset Alivio, Shimano -
Suspension Hardtail -
Drivetrain 2 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 171cm
MD
169cm - 180cm
LG
190cm - 200cm
XL
195cm - 205cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alu 6061 T6 Double Butted, Smooth Welding, Sport Geometry, Conical Head Tube, BB BSA 73 mm, IDK dropout, Smoot Welding, Inner cable routing
Suspension Fork
SR Suntour XCM HLO, 1-1/8", Coil, QR Type, Hydraulic Lockout, 100mm travel
Drivetrain
Rear Derailleur
SHIMANO ALIVIO RD-M3100 Shadow
Front Derailleur
SHIMANO FD-M3120-M, SIDE SWING, FRONT-PULL
Shift Levers
SHIMANO ALIVIO SL-M3100-2L RapidFire Plus, 2-speed, SHIMANO ALIVIO SL-M3100-R RapidFire Plus,9-speed
Cassette
SHIMANO CS-HG200-9, 11-36T
Crank
SHIMANO FC-MT101, 36-22T
Bottom Bracket
SHIMANO BB-UN101 122.5mm, BSA, shell 73mm
Chain
KMC X9
Pedals
Marwi SP-610
Wheels
Front Hub
SHIMANO HB-TX505, 32H, CENTER LOCK, QR Type
Rear Hub
SHIMANO FH-TX505-8, 32H, CENTER LOCK, M10x135mm, QR Type
Rims
Stars J25DH, 32H
Spokes
Sapim Galvanized Black
Tires
Schwalbe Smart Sam, 29x2.10"
Brakes
Brakes
SHIMANO BL-MT200/BR-MT200, hydraulic disc brake
Cockpit
Stem
ONE1 Sport MAS-D61248 Alloy, 31.8mm, -8°
Handlebar
ONE1 Alloy, MTB AL-312BT, 9° backsweep, 12mm rise, 740mm, 31.8mm
Grips
ONE1 VLG-1661D2N, Lock-On
Seat
Saddle
Selle Royal Vivo HRN
Seatpost
ONE1 Sport Alloy, SP C207, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.66 mm | 1.64 mm | 1.56 mm | 1.55 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 628 mm | 649 mm | 669 mm | 690 mm |
| Rake | 46 mm | 45 mm | 45 mm | 46 mm |
| Trail | 87 mm | 88 mm | 88 mm | 87 mm |
| Stack | 626 mm | 645 mm | 645 mm | 663 mm |
| Reach | 378 mm | 393 mm | 413 mm | 427 mm |
| Top Tube Length | 576 mm | 596 mm | 616 mm | 636 mm |
| Seat Tube Angle | 72.4 ° | 72 ° | 72 ° | 72.4 ° |
| Seat Tube Length | 406 mm | 457 mm | 508 mm | 559 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 100 mm | 120 mm | 120 mm | 140 mm |
| Chainstay Length | 451 mm | 451 mm | 451 mm | 451 mm |
| Wheelbase | 1072 mm | 1093 mm | 1113 mm | 1134 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 160 cm | 169 cm | 190 cm | 195 cm |
| Rider Max Height | 171 cm | 180 cm | 200 cm | 205 cm |
About this model
XC 859 is part of the Superior Xc model. There are 27 bikes that carry this model name. You can easily view all of the Superior Xc bikes models from 2021, here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Crosscountry bikes average price
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for Crosscountry bikes
If we make a quick analysis of the average weight of a Crosscountry bike, we get 12.4 kg (27.34 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
much heavier than average, XC 859 has a weight of 15 kg (33.07 lbs). In other words, this model is 20.97% heavier than the average Crosscountry bike.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
XC 859 components
Fork
The fork installed on this bike is the SunTour XCM HLO model. The travel on this model is 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
The XC 859 2021 bike is equipped with 29″ aluminum wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
XC 859 comes in 4 sizes, that range from 160 cm – 205 cm (5.25 ft – 6.73 ft). In short, it won’t be difficult to find the right one for you.
