Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork RST BLAZE
-
Groupset Alivio, Shimano -
Suspension Hardtail -
Drivetrain 2 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 171cm
MD
169cm - 181cm
LG
179cm - 191cm
XL
189cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alu 6061 T6 Double Butted, Smooth Welding, Sport Geometry, Geometry, Integrated Cable Routing, BB BSA 73 mm, IDK dropout,
Suspension Fork
RST Blaze, 1-1/8", 100mm travel
Drivetrain
Rear Derailleur
SHIMANO ALIVIO RD-M3100, Shadow Design
Front Derailleur
SHIMANO ALIVIO FD-M3120-M, Side Swing, Front Pull
Shift Levers
SHIMANO ALIVIO SL-M3100, RAPIDFIRE Plus, 2-speed
Cassette
SHIMANO CS-HG200, 9-speed, 11-36T
Crank
SHIMANO FC-MT101, 36-22T
Bottom Bracket
SHIMANO BB-UN101, 122.5mm, BSA, shell 73mm
Chain
KMC X9
Pedals
Marwi SP-610
Wheels
Front Hub
SHIMANO HB-QC300, 32H, CL, M9X100mm, QR Type
Rear Hub
SHIMANO FH-QC300-HM, 32H, CL, M10X135mm, QR Type
Rims
STARS J25D, Disc, 32H
Spokes
SAPIM Galvanized Black
Tires
Schwalbe Smart Sam, KevlarGuard, 29x2.10"
Brakes
Brakes
SHIMANO MT200, hydraulic disc brake
Cockpit
Stem
ONE Sport, Alloy, 31.8mm, -8°°
Handlebar
ONE Alloy, 12mm rise, 740mm, 31.8mm
Headset
ONE CHH1505, 1-1/8“, ZS44/28.6 - ZS56/30
Seat
Saddle
Selle Royal Vivo
Seatpost
ONE Sport, Alloy, 30,9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.55 mm | 1.47 mm | 1.47 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 661 mm | 684 mm | 704 mm | 725 mm |
| Rake | 49 mm | 49 mm | 49 mm | 48 mm |
| Trail | 91 mm | 91 mm | 91 mm | 92 mm |
| Stack | 621 mm | 640 mm | 640 mm | 659 mm |
| Reach | 399 mm | 414 mm | 434 mm | 449 mm |
| Top Tube Length | 576 mm | 596 mm | 616 mm | 636 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 406 mm | 457 mm | 508 mm | 559 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 100 mm | 120 mm | 120 mm | 140 mm |
| Chainstay Length | 448 mm | 448 mm | 448 mm | 448 mm |
| Wheelbase | 1102 mm | 1125 mm | 1145 mm | 1166 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 160 cm | 169 cm | 179 cm | 189 cm |
| Rider Max Height | 171 cm | 181 cm | 191 cm | 200 cm |
Model Overview
XC 859 completes the Superior Xc model. 37 bikes variations carry this model name so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Superior XC 819 W 2023 is the most economical model, with a starting price of 719$. Superior XC 899 2023 on the other hand costs 1058$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Crosscountry bikes
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2023 for 846$. In conclusion, this bike price is 125.18% lower than the price of the average Crosscountry bike.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork
The fork installed on this bike is the RST BLAZE model. The travel on this model is 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
When it comes to wheels, the XC 859 bike is equipped with the 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
When you want to stop the bike in time, the brakes are vital. The XC 859 has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 4 sizes. They vary from 160 cm – 200 cm (5.25 ft – 6.56 ft). In short, you can easily find one that suits you.
