Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Travel Rear 130mm -
Fork RockShox 35 Gold RL
-
Groupset Deore, Shimano -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 171cm
MD
169cm - 181cm
LG
179cm - 191cm
XL
189cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alu X6 Ultralite MTB Trail SU-02, Advanced Geometry, Travel 130 mm, Tapered Head Tube, BB92, 3D alloy one piece link, Alloy swingarm, SR dropout, Boost 12x148 mm, Inner cable routing, Dropped seat post ready
Suspension Fork
RockShox 35 Gold RL, Tapered, DebonAir, 15x110mm axle, 140mm travel
Rear Shock
RockShox Monarch RT, external rebound, 2 position compression (Open/Pedal), size 190x51mm
Drivetrain
Rear Derailleur
SHIMANO DEORE RD-M6100 Shadow Plus
Shift Levers
SHIMANO DEORE SL-M6100-IR RapidFire Plus, 12-speed
Cassette
SHIMANO CS-M6100-12, 10-51T
Crank
SHIMANO FC-MT510, 32T
Bottom Bracket
BB-MT500PA PressFit, shell 41x92mm
Chain
CHAIN SHIMANO CN-M6100
Wheels
Front Hub
SHIMANO HB-MT410-B, 32H, CENTER LOCK, 15x110mm THRU Type AXLE
Rear Hub
SHIMANO FH-MT410, 32H, CENTER LOCK, 12x148mm THRU Type AXLE
Rims
Stars J30D, 32H
Spokes
Sapim Leader, Stainless Black
Tires
Schwalbe Nobby Nic Performance, 29x2.40", ADDIX
Brakes
Brakes
SHIMANO BL-M4100/BR-MT420, hydraulic disc brake
Cockpit
Stem
ONE1 TDS-D622 Alloy, 35mm
Handlebar
ONE1 Alloy, MTB AL-3712BT, 9° backsweep, 12mm rise, 760mm, 35mm
Grips
ONE1 VLG-1661D2N, Lock-On
Seat
Saddle
fizik Taiga
Seatpost
ONE1 Alloy, MT171, dropper post, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.35 mm | 1.29 mm | 1.27 mm |
| Bottom Bracket Height | 344 mm | 344 mm | 344 mm | 344 mm |
| Front Center | 717 mm | 743 mm | 763 mm | 783 mm |
| Rake | 53 mm | 53 mm | 53 mm | 53 mm |
| Trail | 101 mm | 101 mm | 101 mm | 101 mm |
| Stack | 580 mm | 589 mm | 589 mm | 599 mm |
| Reach | 415 mm | 437 mm | 457 mm | 473 mm |
| Top Tube Length | 577 mm | 603 mm | 623 mm | 643 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 393 mm | 431 mm | 482 mm | 533 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 90 mm | 100 mm | 100 mm | 110 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1140 mm | 1166 mm | 1186 mm | 1206 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm | 30 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 160 cm | 169 cm | 179 cm | 189 cm |
| Rider Max Height | 171 cm | 181 cm | 191 cm | 200 cm |
About this model
XF 919 TR completes the Superior Xf model. Superior released 21 bikes variations of this model so far. Take a sneak peek at all Superior Xf bikes models from 2021, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Average weight for Trail bikes
Trail bikes have an average weight of 12.98 kg (28.62 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Weighing 14.8 kg (32.63 lbs), the XF 919 TR model is considerably heavier than average. In short, the average Trail bike weight is 14.02% lower than this one.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork
The XF 919 TR comes factory-installed with the RockShox 35 Gold RL fork. This has a travel range of 140mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The shock that’s installed on this bike is RockShox Monarch RT, with a travel distance of 130mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
The wheels on XF 919 TR are the 29″ aluminum type. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
For your safety, it is important to have quality breaks on your bike. Superior XF 919 TR has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
XF 919 TR comes in 4 sizes, that range from 160 cm – 200 cm (5.25 ft – 6.56 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Superior XF 919 TR comes with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
