Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 29" -
Travel Front 140mm -
Travel Rear 130mm -
Fork RockShox 35 Gold RL
-
Groupset Deore, Shimano -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alu X6 Ultralite MTB Trail SU-02, Advanced Geometry, Travel 130 mm, Tapered Head Tube, BB92, 3D alloy one piece link, Alloy swingarm, SR dropout, Boost 12x148 mm, Inner cable routing, Dropped seat post ready
Suspension Fork
RockShox 35 Gold RL, Tapered, DebonAir, 15x110mm axle, 140mm travel
Rear Shock
Bushing body for RockShox, RockShox Monarch RT, external rebound, 2 position compression (Open/Pedal), size 190x51mm
Drivetrain
Rear Derailleur
SHIMANO DEORE RD-M6100 Shadow Plus
Shift Levers
SHIMANO DEORE SL-M6100-IR RapidFire Plus, 12-speed
Cassette
SHIMANO CS-M6100-12, 10-51T
Crank
SHIMANO FC-MT510, 32T
Bottom Bracket
SHIMANO BB-MT500PA PressFit, shell 41x92mm
Chain
SHIMANO DEORE CN-M6100
Wheels
Front Hub
SHIMANO HB-MT410-B, 32H, CENTER LOCK, 15x110mm THRU Type AXLE
Rear Hub
SHIMANO FH-MT410-B, 32H, CENTER LOCK, 12x148mm THRU Type AXLE
Rims
Stars J30D, 32H
Spokes
Sapim Leader, Stainless Black
Tires
Schwalbe Nobby Nic Performance, 29x2.40", ADDIX
Brakes
Brakes
SHIMANO BL-M4100/BR-MT420, hydraulic disc brake
Cockpit
Stem
ONE1 TDS-D622 Alloy, 35mm
Handlebar
ONE1 Alloy, MTB AL-3712BT, 9° backsweep, 12mm rise, 760mm, 35mm
Grips
ONE1 VLG-1661D2N, Lock-On
Seat
Saddle
Saddle
Seatpost
ONE1 Alloy, MT171, dropper post, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.42 mm | 1.36 mm | 1.33 mm |
| Bottom Bracket Height | 349 mm | 349 mm | 349 mm | 349 mm |
| Front Center | 716 mm | 742 mm | 762 mm | 782 mm |
| Rake | 49 mm | 49 mm | 49 mm | 49 mm |
| Trail | 113 mm | 113 mm | 113 mm | 113 mm |
| Stack | 591 mm | 600 mm | 600 mm | 610 mm |
| Reach | 400 mm | 422 mm | 442 mm | 458 mm |
| Top Tube Length | 577 mm | 603 mm | 623 mm | 643 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 393 mm | 431 mm | 482 mm | 533 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 90 mm | 100 mm | 100 mm | 110 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1140 mm | 1166 mm | 1186 mm | 1206 mm |
| Bottom Bracket Drop | 25 mm | 25 mm | 25 mm | 25 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
XF 919 TR is part of the Superior Xf model. 21 bikes variations carry this model name so far. Take a sneak peek at all Superior Xf bikes models from 2022, by clicking here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Trail bikes
If you want an acceptable Trail bike you should know that the average price is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork
The XF 919 TR comes factory-installed with the RockShox 35 Gold RL fork. This has a travel range of 140mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
The XF 919 TR has a rear shock with a travel of 130mm. The model Bushing body for RockShox is the one installed in this bike. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
As for the wheels, Superior XF 919 TR 2022, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Superior XF 919 TR includes a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
