Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork RockShox Judy Silver TK
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 171cm
MD
169cm - 181cm
LG
179cm - 191cm
XL
189cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alu X6 Ultralite, Race Geometry, Tapered Head Tube, BB92, SR dropout, Boost Thru axle 12x148mm, Inner Cable Routing
Suspension Fork
RockShox Judy Silver TK R, Tapered, SoloAir, 15x110mm axle, 100mm travel
Drivetrain
Rear Derailleur
SHIMANO DEORE RD-M5100 Shadow Plus
Shift Levers
SHIMANO DEORE SL-M5100-IR RapidFire Plus, 11-speed
Cassette
SHIMANO CS-M5100-11, 11-51T
Crank
ONE1 TAM38-DB36NC, 36T
Bottom Bracket
BB-MT500PA PressFit, shell 41x92mm
Chain
KMC X11
Wheels
Front Hub
SHIMANO HB-MT410-B, 32H, CENTER LOCK, 15x110mm THRU Type AXLE
Rear Hub
SHIMANO FH-MT400-B, 32H, CENTER LOCK, 12x148mm THRU Type AXLE
Rims
Stars J25DH, 32H
Spokes
Sapim Leader, Stainless Black
Tires
Schwalbe Rapid Rob KevlarGuard, 29x2.10"
Brakes
Brakes
SHIMANO BL-M4100/BR-MT410, hydraulic disc brake
Cockpit
Stem
ONE1 TDS-RD507 Alloy, 31.8mm, -7°
Handlebar
ONE1 Race, Horizon Bow, 9° backsweep, 5mm rise, 760mm, 31.8mm
Grips
ONE1 VLG-1661D2N, Lock-On
Seat
Saddle
fizik Taiga
Seatpost
ONE1 Race Alloy, SP 218, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.38 mm | 1.34 mm | 1.32 mm |
| Bottom Bracket Height | 319 mm | 319 mm | 319 mm | 319 mm |
| Front Center | 671 mm | 696 mm | 717 mm | 738 mm |
| Rake | 45 mm | 44 mm | 44 mm | 44 mm |
| Trail | 96 mm | 97 mm | 97 mm | 97 mm |
| Stack | 584 mm | 593 mm | 602 mm | 612 mm |
| Reach | 408 mm | 430 mm | 448 mm | 465 mm |
| Top Tube Length | 578 mm | 603 mm | 623 mm | 643 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 393 mm | 431 mm | 482 mm | 533 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1098 mm | 1123 mm | 1144 mm | 1165 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm | 55 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 160 cm | 169 cm | 179 cm | 189 cm |
| Rider Max Height | 171 cm | 181 cm | 191 cm | 200 cm |
Model Overview
XP 909 completes the Superior Xp model. 20 bikes variations carry this model name so far. You can get a glimpse at all models from 2021, by clicking on this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Crosscountry bikes
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Crosscountry bikes average weight
On a deeper look, we notice that the average weight of a Crosscountry bike is 12.4 kg (27.34 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
XP 909 weighs 12.6 kg (27.78 lbs) and is slightly heavier than the average. In conclusion, the average Crosscountry bike weighs 1.61% less than XP 909.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
XP 909 components
Fork
The XP 909 comes factory-installed with the RockShox Judy Silver TK fork. This has a travel range of 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
As for the wheels, Superior XP 909 2021, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
Nothing is more important on a bike than its ability to brake properly. Superior XP 909 is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
XP 909 comes in 4 sizes, that range from 160 cm – 200 cm (5.25 ft – 6.56 ft). In short, it won’t be difficult to find the right one for you.
