Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame aluminium -
Wheels 29" -
Travel Front 100mm -
Fork RockShox Judy Silver TK
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alu X6 Ultralite, Race Geometry, Conical Head Tube, BB92, Boost Thru axle 148x12mm, Inner cable routing
Suspension Fork
RockShox Judy Silver TK R, Tapered, SoloAir, 15x110mm axle, 100mm travel
Drivetrain
Rear Derailleur
SHIMANO DEORE RD-M5100 Shadow Plus
Shift Levers
SHIMANO DEORE SL-M5100-IR RapidFire Plus, 11-speed
Cassette
SHIMANO CS-M5100-11, 11-51T
Crank
ONE1 TAM38-D34NC, 34T
Bottom Bracket
SHIMANO BB-MT500PA PressFit, shell 41x92mm
Chain
KMC X11
Wheels
Front Hub
SHIMANO HB-MT410-B, 32H, CENTER LOCK, 15x110mm THRU Type AXLE
Rear Hub
SHIMANO FH-MT400-B, 32H, CENTER LOCK, 12x148mm THRU Type AXLE
Rims
Stars J25DH, 32H
Spokes
Sapim Leader, Stainless Black
Tires
Schwalbe Rapid Rob KevlarGuard, 29x2.10"
Brakes
Brakes
SHIMANO BL-M4100/BR-MT410, hydraulic disc brake
Cockpit
Stem
ONE1 TDS-D507 Alloy, 31.8mm, -7°
Handlebar
ONE1 Race, Horizon Bow, 9° backsweep, 5mm rise, 760mm, 31.8mm
Grips
ONE1 VLG-1661D2N, Lock-On
Seat
Saddle
Saddle
Seatpost
ONE1 Race Alloy, SP 218, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.38 mm | 1.34 mm | 1.32 mm |
| Bottom Bracket Height | 319 mm | 319 mm | 319 mm | 319 mm |
| Front Center | 671 mm | 696 mm | 717 mm | 738 mm |
| Rake | 45 mm | 44 mm | 44 mm | 44 mm |
| Trail | 96 mm | 97 mm | 97 mm | 97 mm |
| Stack | 584 mm | 593 mm | 602 mm | 612 mm |
| Reach | 408 mm | 430 mm | 448 mm | 465 mm |
| Top Tube Length | 578 mm | 603 mm | 623 mm | 643 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 393 mm | 431 mm | 482 mm | 533 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1098 mm | 1123 mm | 1144 mm | 1165 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm | 55 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
XP 909 is a Superior Xp model. Superior released 20 bikes variations of this model so far. You can easily view all of the Superior Xp bikes models from 2022, here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
XP 909 components
Fork
The fork installed on this bike is the RockShox Judy Silver TK model. The travel on this model is 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
As for the wheels, Superior XP 909 2022, has a 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
Nothing is more important on a bike than its ability to brake properly. Superior XP 909 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
XP 909 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
